Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Specifications
Brand Name :
SANROCK
Model Number :
Customized
Certification :
CE ISO 9001:2015
Place of Origin :
Zhejiang, China
MOQ :
1 Set/Sets
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000Set/Sets per Month
Delivery Time :
18-25 work days
Packaging Details :
Nude package for machines, Wooden box package for spare parts, Or customer demand.
Product name :
Screw Air Compressor,Air Compressor Machine
Name :
Diesel Screw Air Compressor
Power :
410KW
Power Source :
Diesel
Pressure :
21-25bar/21-34bar
Air consumption :
31-29m²/min 36.5-32m²/min
Speed :
1600/1400rpm 1830/1400rpm
Fuel tank capacity :
700L
Lubricating oil capacity :
120L
Cooling method :
Both Air/Water Cooling Available
Application :
Mining Project,Coal,Ore
Type :
Screw
Core components :
PLC, Pressure vessel, Engine, motor, Pump, Bearing
configuration :
Stationary
Dimension(l*w*h) :
4100*1800*2050mm
Weight :
5600KG
Description

screw air compressor used with water well drilling rig
This specialized rotary screw air compressor is engineered to deliver high-efficiency compressed air supply for water well drilling operations.
Featuring robust twin-screw technology, to power down-the-hole hammers and rotary drilling systems. superior cooling and lubrication for extended duty cycles in harsh drilling environments.
Integrated with vibration-resistant components and heavy-duty filtration systems, this compressor maintains high performance under dust and high-temperature conditions.
Automatic load/unload controls and energy-saving VFD options enhance fuel efficiency for mobile drilling rig configurations. With protection rating and corrosion-resistant coatings, it meets rigorous drilling industry standards for reliability in borewell construction and geothermal drilling applications.

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air CompressorSkid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air CompressorSkid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air CompressorSkid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Products Description

Brand Name:Sanrock
Product name: screw air compressor
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air CompressorSkid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air CompressorSkid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor
Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air CompressorSkid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Company Profile

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

Skid Mounted Screw Air Compressor Diesel Engine Rotary Screw Drive Air Compressor

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.

2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.

3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
