Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Specifications
Brand Name :
SANROCK
Model Number :
YT26
Certification :
CE ISO 9001:2015
Place of Origin :
Zhejiang, China
MOQ :
1Set/Sets per Month
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000Set/Sets per Month
Delivery Time :
15-25days
Packaging Details :
Nude package for machines, Wooden box package for spare parts, Or customer demand.
Product name :
Jack Hammer
Name :
Portable Pneumatic rock drill
Drilling Diameter :
34-42mm
Drilling Depth :
1-6m
Application :
Mining ,blast hole drilling,metallurgy, coal,railway, transportation
Feature :
High Drilling Efficiency,High Performance
Working Pressure(bar) :
0.4-0.63Mpa
Drill rod diameter :
Hex 22*108
Impact Energy :
≥30 J
Impact Frequency :
≥23 Hz
Air Consumption :
≤47 L/S
Dimension(L*W*H) :
650 x 240 x 202mm
Weight :
26KG
Description

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

YT26 pneumatic rock drill is an important tool for rock drilling operation in mines, railway, communication and water conservancy projects. Suitable for making horizontal and inclined blast holes in medium-hard and hard rocks.

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Feature:
1.Fit for wet drilling in medium-hard or hard rock.
2.Grouped control mechanism,quick to start up, with "air on ,water on, air off,water off" mechanism,convenient to handle andeasy to maintain and repair.
3.Long service life of parts, parts highly interchangeable and reliable performance.
4.YT26 differ form similar products particularly in its high efficiency, strong flushing and powerful torque.

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig MachineAir Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Products Description

Product Name:Pneumatic rock drill
Key Selling Points:efficient and low energy consumption
Working Pressure(bar):0.4-0.63Mpa
Drilling Depth:5m
Drilling Diameter:32mm-42mm
Shank size:H22x108mm
Impact Energy: ≥30 J
Impact Frequency: ≥23 Hz
Air Consumption: ≤47 L/S
Air Pipe Inner Diameter: 19 mm
Water Pipe Inner Diameter: 13 mm
Dimension(L*W*H):650 x 240 x 202 mm
Weight:26 KG
Application:mining ,concrete breaking,metallurgy, coal,railway
Feature:easy Operation,light weight, high drilling efficiency

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig MachineAir Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig MachineAir Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Company Profile

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.

2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.

3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
