Specifications
Place of Origin :
China
Brand Name :
Dongsheng
Certification :
The Third Party
Model Number :
DSKD5040
Description

As Electromagnets also Holding Magnets develop high attraction forces to flat magnetic materials - but they don't need electrical power and therefore they can't be switched off. Holding Magnet devices comprise of a permanent magnet, encased in a mild steel pot which provides a return flux path.

Holding Magnets Sucker Solenoids︱Power-losing Electromagnets (IR-CUT︱Solenoid Valve︱Solenoid pump︱Solenoid Coil)

1. Main size: Diameter—40mm, Height—50mm

Holding Magnets Sucker Solenoids︱Power-losing Electromagnets︱Tubular Electromagnets

2. Feature:

1) The great adsorption force has been produced thanks to the built-in permanent magnet with super suction without being charged

2) Tubular design

3) Power-losing type

General Specifications of the Power-losing Electromagnets
No. Name

Result
1 Operating Voltage

DC 6~48V
2 Dielectric Strength

AC500V(50/60Hz) 1min
3 Duty Cycle

ED 50%
4 Working Temp.

-10℃~180℃
5 Temp. Rise

DC12V,below75℃
6 Holding Force

500N

3. Service life: ten million times (Power-on : 2s, power-off: 2s)

4. Advantage:

1) Small current can release the load

2) Strong adsorption

3) Energy-saving

4) Easy to control

5. Application:

It is mainly used in electromagnetic suction door, robots, locks, toys, games, textile machinery, medical equipment and the other automatic control system.
