High-efficiency and energy-saving milk powder spray dryer
High-efficiency and energy-saving milk powder spray dryer
High-efficiency and energy-saving milk powder spray dryer
High-efficiency and energy-saving milk powder spray dryer
High-efficiency and energy-saving milk powder spray dryer
High-efficiency and energy-saving milk powder spray dryer
Specifications
Model Number :
LPG
MOQ :
2 sets
Material :
Stainless steel, carbon steel
Brand Name :
suli
Heat source :
Steam, gas, thermal oil, coal/biomass hot air furnace
Payment Terms :
L/C, T/T
Packaging Details :
According to customer requirements
Production requirements :
Made according to customer requirements
Certification :
ISO9001
Price :
Negotiation
Place of Origin :
China
Description
High-Efficiency and Energy-Saving Milk Powder Spray Dryer
Product Overview
This specialized equipment is designed for dairy products including whole/skim milk powder, goat milk powder, whey powder, and infant formula. It rapidly dries liquid emulsions into uniform powder while preserving original nutrients, color, and flavor.
Core Advantages and Technical Features
  • Nutritional Protection and Flavor Retention: Low-temperature rapid drying technology minimizes heat damage and prevents discoloration or burnt taste
  • High Solubility for Reconstitution: Optimized atomizer speed and airflow field ensure uniform powder particles with excellent solubility
  • Aseptic and Hygienic Design: Tower body with no dead corners and polishing precision of Ra < 0.4µm, meeting FDA/GMP requirements
  • Anti-Stickness Technology: Equipped with tower wall cooling jacket or air sweeping device to prevent powder adhesion and spoilage
Scope of Application
Whole milk powder, skim milk powder, formula milk powder, whey powder, colostrum powder, camel milk powder, goat milk powder, modified milk powder, and other food-grade heat-sensitive liquid materials.
Technical Specifications
Model/Item/Parameter 5 25 50 150 200-2000
Inlet Temperature 140-350 self-control
Output Temperature 80-90
Water Evaporation (kg/h) 5 25 50 150 200-2000
Centrifugal Spray Head Transmission Form Compressed air transmission Mechanical transmission
Rotating Speed (r.p.m) 25000 18000 18000 15000 8000-15000
Spray Disc Diameter (mm) 50 120 120 150 180-240
Heat Source Electricity Steam + electricity Steam + electricity, oil, gas, hot air stove
Electric Heating Power (kw) 9 36 72 99
Overall Dimensions (L×W×H)(m) 1.8×0.93×2.2 3×2.7×4.26 3.5×3.5×4.8 5.5×4×7 Determine according to actual situation
Dry Powder Recycling (%) ≥95
Note: The amount of water evaporation is related to material characteristics and hot air inlet/outlet temperatures. When outlet temperature is 90°C, the water evaporation curve is shown above (for model selection reference). Parameters subject to change without prior notice due to product updates.
Ordering Instructions
  • Name and physical properties of material liquid: solid content, viscosity, surface tension, and PH value
  • Powder capacity after drying, allowable residual moisture content, particle size, and maximum temperature
  • Output and daily opening hours
  • Available energy: steam pressure, electrical capacity, available coal, oil, and gas
  • Control requirements: Automatic control of inlet and outlet temperatures
  • Powder collection requirements: Bag trap installation and environmental requirements for exhaust emissions
  • Other special requirements
