YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
Specifications
Brand Name :
Sinolift
Model Number :
YL520
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5000sets/moNth
Delivery Time :
15 days
Packaging Details :
Sandard Export Package
Product Name :
YL520 Semi Electric Hydraulic Drum Dumper With Maintenance Free Battery Loading Capacity 520Kg Lift Height 1600mm
Type :
Semi Electric
Lifting Height :
1600mm
Loading Capacity :
520Kg
Outline Dimension :
1400X1000X2060mm
Pump Unit Powern :
1.5KW/H
Lifting Speed :
120mm/S
Battery :
120Ah/12V
Net Weight :
264Kg
Warranty :
1 year
After Service :
On-line service,Spare parts
Description

Feature:

- High quality hydraulic power unit and maintenance-free battery;

- Special rolling technology of C-type frame is with strong security;

- Combined Eagle-grip and Anchor ear structure, suitable for electric rotation of steel drums and plastic drums;

Specification:

Model 　 YL520
Loading Capacity kg 520
Drum size 　 55 gallon ( (Ø572x900) steel, 210L plastic
Lifting Height mm 1600
Wheel Dimension mm Ø80x55/Ø150x50
Inner/Outer Width of Front Leg mm 640/800
Turning Radius mm 1750
Pump Unit Power KW/h 1.5
Battery Parameter Ah/V 120/12
Lifting Speed mm/s 120
Outline Dimension (LxWxH) mm 1400*1000*2060
Net weight kg 264
