With the rapid development and popularization of drone technology, drones have shown great application potential in aerial photography, agriculture, rescue, security and other fields, but at the same time they have also brought increasingly serious safety risks. Incidents such as illegal intrusions, malicious reconnaissance, and privacy violations occur frequently, posing serious threats to national security, public safety, and personal privacy. Therefore, the development of efficient and advanced drone jamming technology has become an urgent need to maintain airspace security and ensure social stability.

The key advantages include:

• AOA Proprietary logarithmic antenna calculation method for precise FPV direction finding.
• The protocol cracking/decoding range is significantly extended, with Remote Id (Drone ID) detection distance of up to 15 kilometers.
• Utilizing proprietary SDR signal control technology to effectively allocate and transmit active white noise across targeted frequency bands.

1. Detection range: In an interference-free environment, signal reception range maybe vary when different antennas are used. the range of detection can up to 10km.
2. Detection spectrum bandwidth: 70 MHZ - 6GHZ, focus on the 433Mhz,868Mhz,915Mhz,2.4Ghz,5.2Ghz,5.8Ghz；
3. FPV Detection:300Mhz-6.2Ghz Analog Signal of FPV Drones,range up to 1-3km
4. Drones Location:For UAVs with Remote ID (China GB42590-2023, US ASTM F3411-22a, EU ASD-STAN PrEN4709-002) and Drone ID (such as DJI Mavic2, Mavic3, air3s, Matrice4, etc., some require network decryption), it can parse detailed information such as drone location and pilot location up to 3-5km.
5. Identify Range: LightBridgel, LightBridge2, Ocusync 1,2,3, WIFI and WIFI variant protocols, Zigbee, Bluetooth and other customized protocal of small brand, can identify UAV brands and models;
6. The trajectory: have the function for tracking flight trajectory.
7. Accurate recognition: it can accurately identify UAV model and electronic fingerprints (ID),≧ 400 different uavs models and the corresponding ID (identity) can be identify at the same time.
8. Detection Angle: 360 °
9. Detection number of UAV : ≧150pcs
10. The lowest detection height: ≤0 meters
11. Detection rate: ≧99.9%
12. Broadband Jamming: 800-900Mhz1.2Ghz1.5 GHz2.4 GHz5.1-5.2GHz5.8GHz
13. [NOTE: The Systemcan be customize with 8-10 frequency, Ex: 433Mhz800-900 MHz; 1.2Ghz; 1.4Ghz; 1.5 GHz; 2.4 GHz; 5.1-5.2GHz; 5.8GHz]
14. support at the level of effective interception Angle range in a straight line dive and turned to flight of UAV, intercept distance: 2km;
15. power supply mode: 220 V±10V
16. Protection grade: ≧IP65
17. Working temperature: - 40 ℃ ~ + 55 ℃
