Full Bore Retrievable Packer Parts / Redress Kit for RTTS Packer
Full Bore Retrievable Packer Parts / Redress Kit for RTTS Packer
Full Bore Retrievable Packer Parts / Redress Kit for RTTS Packer
Full Bore Retrievable Packer Parts / Redress Kit for RTTS Packer
Specifications
Brand Name :
ZZ TOP OIL TOOLS
Model Number :
RTTS Packer Parts
Certification :
ISO, API
Place of Origin :
China
MOQ :
1 set
Price :
USD 1-10000/set
Payment Terms :
L/C, T/T, D/P
Supply Ability :
10 set/month
Delivery Time :
30-50 days
Packaging Details :
Pollywood
Product :
Redress kit for Casing Packer
Material :
Alloy Steel / Inconnel
Size :
4 1/2 inch to 20 inch
Working Pressure :
10000psi
Application :
Oil & Gas Well Dowhole Drill Stem Testing Service
Connection :
IF, EUE , CAS
Working Condition :
Oil & Gas & H2S service
Working Temperature :
Up to 425oF
Description

Full Bore Retrievable Packer Parts / Redress Kit for RTTS Packer

The RTTS Packer is full bore retrievable packer, RTTS is the Halliburton type. The full opening permits pumping large volumes of fluid with a minimum pressure drop, and allows the passage of a through tubing type perforating gun which helps make the tool usable for multiple operations with one trip in the hole-such as perforate, test, treat, squeeze, perforate, etc. Generally, the tool is composed of a packer body assembly and circulating valve assembly.

ZZ TOP supply the RTTS Packer Redress kit / Spare parts interchangeable with Halliburton types.

Below is the list of ordered Packer Parts

No. Description Qty Unit
1 TOP SHOE 2 Ea
2 MECHANICAL SLIP 60 Ea
3 HYDRAULIC HOLDDOWN BODY, 17-4PH+Q PQ 10 Ea
4 HOLD STRAP 36 Ea
5 HYDRAULIC SPRING, SMALL 162 Ea
6 HYDRAULIC SPRING, BIG 162 Ea
7 HYDRAULIC SLIP, 17-4PH+Q PQ 90 Ea
8 SLIP SCREW 120 Ea
9 BOLT 24 Ea
10 SCREW 24 Ea
11 MECHANICAL SLIP BODY 1 Ea
12 SCREW 30 Ea
13 SCREW 50 Ea
14 KEEPER RING 2 Ea
15 VOLUME TUBE, 17-4PH+Q PQ 10 Ea
16 DRAG BLOCK 12 Ea
17 DRAG BLOCK SPRING 60 Ea
18 HYDRAULIC SLIP BODY, 17-4PH+Q PQ 4 Ea
19 SLIP SCREW 63 Ea
20 HYDRAULIC SPRING 72 Ea
21 HOLD STRAP 27 Ea
22 HYDRAULIC SLIP, 17-4PH+Q PQ 36 Ea
23 SCREW 20 Ea
24 SLIP STOPPIN 32 Ea
25 MECHANICAL SLIP 24 Ea
26 VOLUME TUBE, 17-4PH+Q PQ 5 Ea
27 SCREW 30 Ea
28 SCREW 30 Ea
29 KEEPER 2 Ea

Specifcation of Full Bore Retrievable Packer / RTTS Packer

Size(in) Casing Range(lb/ft) Size(in) Casing Range(lb/ft)

4 1/2

 9.5 8 5/8 24-49
15.1-18.1

9 5/8

 40-71.8
11.6-13.5 29.3-53.5

5

 23

10 3/4

 32.75-55.5
15-18 60.7-81
11.5-13

11 3/4

 38-54

5 1/2

 23-26 60-71
20-23

13 3/8

 48-72
13-20 72-98
6 15-23

16

 75-109
6 5/8 24-32 109-146

7

 17-38 18 5/8 78-118
49.5

20

 94-133
7 5/8 20-39 169-204
