Specifications
Brand Name :
ATO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
10 [PIECES PER MONTH
Delivery Time :
10-15 WORK DAYS
Packaging Details :
WOODEN BOX
Viberation Motor :
2*0.75Kw
Screen Size(mm) :
750*900
Capacity :
45 m3 / h (200GPM)
Adjustable G Force :
Less than 7.1 G
Description

Shale Shaker Screen Viberation Motor 2*0.75Kw Viberation Amplitude 3.92~5.62 mm

Descriptions of Shale Shaker Screen Viberation Motor 2*0.75Kw Viberation Amplitude 3.92~5.62 mm:

We can design double shakers and truplicate shakers on single skid according to client's special requirements and also supply relevant connection manifold according to xurrent industry situation, we provide both third reneration liner motion shale shaker and fourth generation balanced elliptical shale shaker.
Shale shaker absorbed advanced tech at home and abroad, complete series shale shaker can meet custimers variablr demand. Client feedback proved the advantages for this kind of shale shaker: high G-force, wide screen area, compressed structure, cost-effective, etc.

Specifications :

Model ZS752E-DM ZS703F-HB ZS703E-DZ ZS954E-HB ZS706E-HB
Viberation Model Liner Motion Liner Motion Liner Motion Liner Motion Liner Motion
Capacity 45 m3 / h
(200GPM)		 120 m3 / h
(528GPM)		 140 m3 / h
(616GPM)		 120 m3 / h
(528GPM)		 120 m3 / h
(528GPM)
Viberation Motor 2*0.75Kw 2*1.72Kw 2*1.72Kw 2*1.72Kw 2*1.94Kw
Screen Qty 2 Panels 3 Panels 3 Panels 4 Panels 6 Panels
Screen Area 1.35 m2 2.63 m2 2.63 m2 2.7 m2 Upper layer
2.0 m3
Screen Size(mm) 750*900 700*1250 700*1250 585*1165 Upper layer
Adjustable G Force Less than 7.1 G Less than 7.5 G Less than 7.5 G Less than 7.5 G Less than 7.5 G
Viberation Amplitude 3.92~5.62 mm 4.14~5.96 mm 4.14~5.96 mm 4.14~5.96 mm 4.14~5.96 mm
Deck Angle Range 20 -1~+50 -1~+50 -1~+50 -1~+50
Weir Height 710 mm 735 mm 1042 mm 735 mm 895 mm
Ex Standard Exd BT4 / IEC Ex / ATEX Exd BT4 / IEC Ex / ATEX Exd BT4 / IEC Ex / ATEX Exd BT4 / IEC Ex / ATEX Exd BT4 / IEC Ex / ATEX
Weight 910 kg 1550 kg 1700 kg 1600 kg 1870 kg
Dimension(mm) 1670*1730*1070 2370*1940*1270 2500*1980*1480 1940*1940*1270 2730*2030*1430
