Specifications
Brand Name :
Shitan
Model Number :
Small 100 meter drilling machine
Place of Origin :
Hebei China
MOQ :
1 set
Price :
35000 USD-45000 USD
Payment Terms :
T/T, Western Union
Supply Ability :
2000 sets/month
Delivery Time :
15-20 days
Packaging Details :
Wooden box
Product Name :
Crawler Mounted Water Drilling Rig
Drilling depth :
30-100m
Drilling diameter :
Φ50-Φ100mm
Rotating torque :
3000
Drilling pipe diameter :
Φ60mm
Diesel engine power :
28HP
Dimension :
2000mm*1200mm*1200mm
Weight :
1.5T
Description
Summary of tracked hydraulic drilling rig:
Working principle:
Positioning and Stability: After the equipment is moved to the work site, the body is fixed with legs and the drilling arm angle is adjusted to align with the drilling position.
Impact rock breaking: The air compressor outputs high-pressure gas (or hydraulic oil) to drive the high-frequency reciprocating motion of the piston inside the impactor (usually 500~1500 times/minute). The piston directly impacts the drill bit, transmitting the impact force to the surface of the rock, causing brittle fracture of the rock.
Rotation assistance: The drill rod drives the drill bit to rotate synchronously (at a speed of about 10-30 revolutions per minute), and the broken rock debris is discharged through the center hole of the drill rod, while ensuring the accuracy of the drilling direction.
Propulsion and slag discharge: The hydraulic propulsion system pushes the drill rod forward, and high-pressure gas or water flows through the center hole of the drill rod to discharge the rock debris outside the hole, forming a continuous drilling operation.

Technical Parameters:

Product Name Small 100 Meter Crawler Mounted Drilling Rig Machine
Drilling Depth 30m-100m
After Sales Service Online Support
Drilling Rod Diameter 60 Mm
Weight 1.5T
Color Yellow, blue, red
Drilling Diameter 50mm-100mm
Rotating torque 3000
Dimension

2000mm*1200mm*1200mm
Drill pipe length 1.5m

Performance characteristics Efficient, flexible, and durable engineering advantages
Strong adaptability: The tracked chassis can climb slopes of more than 30 degrees, adapt to complex terrains such as mines, tunnels, and water conservancy projects, and do not require additional leveling of the site.
High drilling efficiency: The high-frequency impact of the impactor, combined with rotational motion, can drill at a speed of 1-3 meters per minute in medium to hard rocks (compressive strength of 80-300 MPa), with a typical aperture range of 80-300 mm.
Automation level: Some models are equipped with electronic control systems that can automatically adjust impact parameters and propulsion speed, reducing manual operation intensity.
Durability: Key components such as impactor pistons and drill bits are made of wear-resistant alloy materials, combined with hydraulic system overload protection to reduce the frequency of failures.
Application field Main force of hard rock drilling in engineering construction
Mining: Blasting hole drilling in open-pit mines, used for drilling operations before ore mining; Development drilling of underground mine tunnels.
Basic engineering: Water conservancy and hydropower engineering (dam foundation, slope anchoring holes), transportation construction (advanced drilling of highway tunnels and railway culverts).
Geotechnical engineering: anchor cable holes for foundation pit support, anti slip pile drilling, and core sampling drilling in geological exploration.
Building materials and municipal engineering: gravel drilling in stone yards, demolition projects in urban construction (such as concrete structure drilling).
