High Pressure BW250 Mud Pump Stable Performance Easy Maintenance
High Pressure BW250 Mud Pump Stable Performance Easy Maintenance
High Pressure BW250 Mud Pump Stable Performance Easy Maintenance
High Pressure BW250 Mud Pump Stable Performance Easy Maintenance
Specifications
Brand Name :
Shitan
Certification :
ISO
Packing Size :
1000*995*650mm
Place of Origin :
Jinzhou ,China
Price :
Negotiable
Delivery Time :
7 days after payment
stroke mm :
100
Horse Power :
18 HP Or Customized/15KW
Input speed rpm :
500
Engine :
Diesel Engine/Motor power
Supply Ability :
1000 sets per month
Cylinder bore mm :
80
weight kg :
500
Product Name :
BW 250 Mud Pump
Inlet Size mm :
76
Payment Terms :
TT,Western Union
MOQ :
1 set
Model Number :
BW 250 Mud Pump
Packaging Details :
Wooden Box
Output :
250L/min
Description

High Pressure BW250 Mud Pump Stable Performance Easy Maintenance

Application BW250 Triplex Mud Pump
The BW250 mud pump is a horizontal three cylinder reciprocating single acting piston pump, featuring a high flow rate of 250 L/min and four variable settings. It is the core supporting equipment for geological core drilling and is widely used in grouting, sewage and other scenarios.

Product Specifications

stroke mm 100
Cylinder bore mm 80 65
Pump speed /min 200 116 72 42 200 116 72 42
flow L/min 250 145 90 52 166 96 60 35
pressure MPa 2.5 4.5 6 6 4 6 7 7
power KW 15
Volumetric efficiency % 83
Total efficiency % 70
Pitch diameter of V-belt pulley mm 410
Type and groove number of V-belt pulley Type b * 5 groove
Input speed rpm 500
Water absorption height m 2.5
Inlet Size mm 76
Push pipe diameter mm 51
Overall dimension mm 1000*995*650
weight kg 500

key features


Four variable levels, wide adaptability: both large and small diameter drilling rigs can be matched to meet different hole depths and geological requirements.
Reliable sealing and long service life: Five dust-proof rings on the pull rod and bowl shaped self sealing polyurethane piston reduce wear and tear.
Maintenance friendly: Good detachable, with steel balls and sound reducing pads for the inlet and outlet valves
Power adaptation: Supports motor/diesel engine drive, suitable for outdoor or construction site conditions.

Typical use


Geological drilling: Transport mud/water into the hole, circulate debris, cool the drill bit, and protect the wall.
Grouting reinforcement: grouting of foundation, tunnel, goaf, and pile foundation, suitable for 1:1 water cement ratio.
Mines and sewage: underground liquid supply, mine sewage, long-distance water delivery.
Supporting drilling machines: core drilling machines, water well drilling machines, are the "blood pumps" of drilling systems.

Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products:

Pneumatic Drilling Rig / Air Drilling Rig(ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.), Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig(ST-30,ST-50,XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines)Crawler Track Undercarriage, Drilling Mud Pump(BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps), Drilling Air Compressor, Water Well Drill Bits(PDC Drill Bit, Tricone Bit, DTH Button Bit), Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter

OEM / ODM can accept. Good quality, professional after-sales service, welcome to order
