Custom Portable Diesel Pneumatic Borewell Machine Water Well Drilling
Custom Portable Diesel Pneumatic Borewell Machine Water Well Drilling
Custom Portable Diesel Pneumatic Borewell Machine Water Well Drilling
Custom Portable Diesel Pneumatic Borewell Machine Water Well Drilling
Specifications
Model :
ST-300
Name :
Pneumatic Borewell Machine
Voltage :
380V
Color :
Red ,Yellow or OEM
Total weight :
8T
Usage :
industrial and civil drilling and geothermal drilling
Power Type :
Diesel
Max drilling depth :
300m
Drilling diameter :
105-300mm
Brand Name :
ShiTan
Model Number :
ST-300
Certification :
ISO
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
2000Set/Year
Delivery Time :
Within 7-12 days
Packaging Details :
Standard export transportation package
Description

Custom Portable Diesel Machine Water Well Drilling Rig For Sale

1.Overview of ST-300 Pneumatic Drilling Rig

ST300 series water well drilling rig is a lightweight, efficient and multifunctional drilling equipment , it is mainly applicable to industrial and civil drilling, geothermal drilling, has the advantages of compact structure, fast advancing, mobile and flexible wide application region etc.. It is especially suitable for water intake in mountainous and rocky strata.Custom Portable Diesel Machine Water Well Drilling Rig For Sale

2.ST-350S Pneumatic Drilling Rig Parameter:

ST300 trailer mounted water well drilling rig
The weight 8T
Drilling diameter 105-300mm
Drilling depth 300m
One-time advance length 4m
Walking speed 2.5km/h
Climbing angles Max.30°
Equipped capacitor 65-70KW
Using air pressure 1.7-3.0Mpa
Air consumption 17-30m³/min
Drill pipe diameter φ50mmΦ76 mm φ89mm
Drill pipe length 1.5m 2.0m 3.0m
Rig lifting force 12T
Swing speed 45-70rpm
Swing torque 3500-5900N.m
Dimension

4m×1.9m×2.3m

3. Advantages of ST-300 pneumatic water well drilling rig:

1. The chassis of the drilling rig adopts a professional walking motor with a reduction box, which has a longer life;

2. The gearbox is cast in one piece, with dual motors providing stronger power, larger torque, more durable, and low maintenance costs;

3. The use of professional excavator chassis, strong and durable, large load-bearing, wide chain plate, little damage to hard roads;

4. Each hydraulic oil pipe is covered with a thick protective jacket to make the service life of the oil pipe longer;

Features:

1.High drilling efficiency, power provided by energy saving motor
2.High efficiency, large rotary torque
3.Simple structure and easy to move
4.Adopt consummate design, long service life
5.Easy to operating

Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：

Pneumatic Drilling Rig / Air Drilling Rig（ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter

OEM / ODM can accept. Good quality, professional after-sales service, welcome to order

Custom Portable Diesel Pneumatic Borewell Machine Water Well DrillingCustom Portable Diesel Pneumatic Borewell Machine Water Well DrillingCustom Portable Diesel Pneumatic Borewell Machine Water Well DrillingCustom Portable Diesel Pneumatic Borewell Machine Water Well DrillingCustom Portable Diesel Pneumatic Borewell Machine Water Well Drilling
