Friction Type Six Ribs Kelly Bar Drilling Iso9001
Friction Type Six Ribs Kelly Bar Drilling Iso9001
Specifications
Brand Name :
JTHL
Model Number :
Kelly bar -1
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
25000$~50000$/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,
Supply Ability :
1000sets/month
Delivery Time :
7 days
Packaging Details :
customer
Place of Origin: :
Shandong, China
Suitable brand :
BAUER, SOILMEC, LIEBHERR, MAIT, TESCAR, IMT, ABI, SANY,
name :
friction kelly bar drilling
keyword :
friction kelly bar drilling
Description

Manufacturer sale high quality friction kelly bar drilling

Friction Kelly Bar

Friction type drill Kelly bar is a kind of drill pipe type with international advanced six-ribs distribution technology composition.The Kelly bar can generate pressure force when the Kelly bar rotarying can produce peripheral force and the rotary passing down the pressure force can produce the friction force. It is simple operation, drilling depth . it is suitable for soft soil layer and mud sand layer.The complete set of Kelly bar is with light weight, high strength, high linearity of the single drill pipe.; The inner and outer layer collocate reasonably , with good wear resistance plate.. it is greatly to meet the special requirement of the drill rig machines.

Product Details

Specification

No.

Diammeter of The First

Section

 Sections Key Pressure Type Length of per section(m) Drill depth Torque(KN.M)
1 ¢299 3 4 Friction 9-14 24-65 100 -120
2 ¢342 3 4 5 Friction 9 - 14 24 - 65 100 -120
3 ¢355 3 4 5 Friction 9 - 14 24 - 65 100-120
4 ¢368 3 4 5 Friction 9 - 14 24 - 65 150-180
5 ¢377 3 4 5 Friction 9 - 14 24 - 65 150-180
6 ¢394 3 4 5 Friction 9 - 15 24 - 70 180-200
7 ¢406 3 4 5 Friction 9 - 15 24 - 70 180-200
8 ¢419 3 4 5 Friction 9 - 15 24 - 70 200-230
9 ¢440(445) 4 5 6 Friction 9 - 15 24 – 85 220-260
10 ¢470 4 5 6 Friction 9 - 18 24 – 102 220-260
11 ¢508 4 5 6 Friction 9 - 18 24 – 102 260-360
12 ¢530 4 5 6 Friction 9 - 20 32 – 114 320-400
13 ¢580(575) 4 5 6 Friction 9 - 24 32 – 138 360-420
14 ¢630 4 5 6 Friction 9 - 26 32 - 150 400-500

Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001

Certificates and Patents
Friction Type Six Ribs Kelly Bar Drilling Iso9001

Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Friction Type Six Ribs Kelly Bar Drilling Iso9001Construction Site
Friction Type Six Ribs Kelly Bar Drilling Iso9001

Welcome Contact Us

Friction Type Six Ribs Kelly Bar Drilling Iso9001

Due to space limitations, not all product details are displayed. For details, please consult Cathy Lee, WhatsApp+8613311085686

Any need feel free connect me please https://api.whatsapp.com/send?phone=8613311085686
After clicking on the link on the phone you can use Whatsapp to contact me directly.We can discuss more details in there .
