Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-HP89
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
China
MOQ :
1
Price :
$65-$889
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
3658 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Material :
HDPE
Product Name :
Hose Floats
Pipe Diameter :
200mm-900mm
Plastic Modling Type :
Mould
Floater Inner Diameter :
220mm-940mm
Floater Outer Diameter :
500mm-2200mm
Color :
Black, Yellow, Orange, Or As Request
Floater Length :
800mm-2500mm
Application :
Dredging Project
Description
Marine Grade Floaters For Hoses
Strong Buoyancy Corrosion Resistant Saltwater Safe
Product Overview
Hongruntong Marine Hose Floats are advanced floatation devices designed for demanding offshore oil and gas operations, marine engineering projects, and long-distance floating pipeline systems. These floats are engineered to maintain consistent buoyancy and structural stability under harsh environmental conditions, including high waves, strong currents, and prolonged exposure to saltwater, UV radiation, and chemical contaminants commonly found in offshore applications.
Manufactured with a high-density polyethylene (HDPE) outer shell and reinforced closed-cell polyurethane foam core, Hose Floats provide exceptional load-bearing capacity while remaining corrosion-resistant and impact-tolerant. The modular split-body design enables installation on pipelines and hoses without disassembly, even in offshore locations where vessel access is limited.
Case Study: North Sea Offshore Oil Field
During an offshore oil field development project in the North Sea, an FPSO vessel required continuous transfer of crude oil using a 600 mm diameter flexible hose. Traditional buoyancy devices failed to provide uniform support, resulting in operational interruptions and accelerated hose replacement cycles.
Hongruntong Marine supplied heavy-duty Hose Floats specifically engineered for the offshore conditions. After deployment, the hose remained consistently afloat, aligned, and properly supported during continuous oil transfer operations. Mechanical stress on hose connectors and joints was reduced, significantly lowering the risk of leakage and unplanned downtime.
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
Technical Specifications
Item Requirements Item Requirements
Tensile Strength ≥13.1MPa Water Absorption 1-2g/100cm²
Break Elongation ≥11.1% Breaking Strength 0.08-0.1MPa
Impact Strength ≥32.4KJ/m² Breaking Elongation 4-6%
Bending Strength ≥15.7MPa Compressive Strength 0.1-0.24MPa
Weather Resistance After total aging energy≥3.5GJ/m² Break Elongation %≥ 10 Oxidative Induction Time 200°Cmm≥ 10
Key Characteristics
  • Good flexibility, excellent impact resistance, particularly suitable for construction in open sea
  • Lightweight weight easy to install and handle, low costs for moving
  • High corrosive resistance, 3 times longer life than steel floats
  • Higher cost performance than steel float
Dimensions & Buoyancy
I.D. (mm) O.D. (mm) Length (mm) Thickness (mm) Net Buoyancy (KGS/Float)
160-180 500 800 4 280
225 600 700 4 320
280 700 900 4 450
340 1000 1000 6 500
410 1100 1100 6 550
460 1200 1200 6 1200
510 1300 1300 7 1250
560 1300 1500 8 1360
610 1400 1600 8 1600
630 1480 1600 8 1950
680 1550 1800 8 2200
730 1620 1900 9 2300
780 1700 2000 9 2700
840 1850 2100 12 3200
890 2000 2400 12 4600
940 2040 2500 13 4900
1150 2400 2600 14 6500
*NOTE: Custom floaters are available.
Key Features
Extreme Load-Bearing and Buoyancy Stability
Hose Floats are designed to support hoses carrying heavy oil, slurry, or chemicals over long distances. The closed-cell foam core provides uniform buoyancy and prevents sagging or partial submersion, ensuring operational stability even under dynamic offshore loads.
Chemical and UV Resistance for Offshore Conditions
The HDPE outer shell is resistant to saltwater corrosion, petroleum products, and UV degradation, ensuring long-term durability in offshore oil and gas environments. The combination of chemical resistance and mechanical toughness extends service life.
Split Body Modular Design for Offshore Installation
The modular split design enables rapid installation on hoses or pipelines without disconnecting the system, minimizing handling risks in offshore conditions. The floats can be easily removed or repositioned for maintenance or hose replacement.
Long Term Reliability and Low Maintenance
Unlike inflatable or metal floatation devices, these Hose Floats maintain consistent buoyancy over time without risk of air leakage or corrosion. Their durable construction ensures minimal maintenance, allowing operators to focus on mission-critical offshore activities.
Applications
  • FPSO Crude Oil Transfer Lines: Used to support floating hoses during oil transfer from offshore platforms to shuttle tankers, ensuring hoses remain aligned and elevated while reducing bending stress and abrasion.
  • Offshore Construction and Dredging Pipelines: Provides stable floatation for temporary or semi-permanent pipelines used in seabed construction, platform tie-ins, or dredging operations in offshore environments.
  • Long Distance Marine Fluid Transfer: Ideal for long floating pipelines transporting water, chemicals, or hydrocarbons between offshore installations, keeping hoses buoyant, aligned, and protected from seabed contact and dynamic loads.
Why Choose Hongruntong Marine
  • Specialized Offshore Engineering Expertise: Extensive experience in supplying floatation solutions for offshore oil and gas projects, understanding the unique challenges of dynamic sea conditions, long hose spans, and chemical exposure.
  • Custom Solutions for Complex Offshore Layouts: We provide tailor-made Hose Floats for specific offshore pipeline layouts, hose diameters, and load requirements, including buoyancy optimization and split-body placement recommendations.
  • Superior Material Selection and Manufacturing Quality: Each float is manufactured with marine-grade HDPE and high-strength closed-cell foam, following strict quality control to ensure structural integrity and consistent buoyancy.
  • Long Term Support and Project Reliability: Comprehensive technical support, including installation guidance, operational advice, and lifecycle management for offshore projects, ensuring reliable performance and client satisfaction.
Frequently Asked Questions
Can Hose Floats withstand exposure to hydrocarbons and chemicals used offshore?
Yes. The HDPE shell and closed-cell foam core are resistant to petroleum products, oils, and common offshore chemicals.
Are these floats suitable for long-distance floating pipelines?
Absolutely. They are engineered for stable buoyancy and load distribution over long spans, maintaining hose alignment and reducing stress.
Can Hose Floats be installed in offshore conditions with waves and current?
Yes. The split-body design allows installation directly onto hoses offshore with minimal handling and maximum operational safety.
What hose diameters are typically supported for offshore oil and gas applications?
Hose Floats can be supplied for diameters from 300 mm up to 1,200 mm, with custom sizes available for specialized offshore pipelines.
How often do these floats require maintenance in offshore operations?
Maintenance is minimal. The durable HDPE shell and closed-cell foam maintain buoyancy and structural integrity over long operational periods without regular intervention.
Product Images
Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance

Saltwater Safe Suction Hose Float Marine Grade Hose Floater Corrosion Resistance
