Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-CHP80
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
China
MOQ :
1
Price :
USD10 to USD390 Per Piece
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1750 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Brand :
Hongruntong Marine
Hose Size :
DN80–1500 (3–60”) as Standard
Hose Length :
Up to 20m (66') as Standard
Name :
Ceramic Hose Pipe
Pressure Rating :
-100kPa to +5000kPa (-14.5psi to +725psi) Higher on request
Material :
Rubber and Ceramic
Reinforcement :
Synthetic Fabric and Wire Helix
Outer Cover :
Uv, Ozone, And Abrasion-Resistant Rubber
Temperature :
30°C to +75°C
Safety Factor :
4:1 as Standard
Application :
Mining Industrial Ceramic
Color :
Black
Description
Thermal Shock Resistant Ceramic Hose Withstands 1000°C Quenching Rapid Cooling Cycles
Product Overview

Thermal Shock Resistant Ceramic Hose Withstands 1000°C Quenching Rapid Cooling Cycles

Food Grade Ceramic Conveyance Hose

FDA/EC1935-compliant with a smooth alumina ceramic interior (Ra ≤0.8µm) for CIP/SIP compatibility. The hygienic clamp connections eliminate dead zones. Resists sugar crystallization, dairy fouling, and abrasive food particles. Temperature range: -40°C to 180°C (steam-cleanable). Options include electropolished stainless ends for pharma/biotech.

Specifications
Tube NR, BR, SBR
Reinforcement High Tensile Steel Wire Spiral
Cover NR, CR
Working Pressure < 25 bars
Flange Material Q235B carbon steel paint
Working Temperature -30℃ to +80℃
Safety Factor 5:1
Application Installed in between the pump and cutter of the dredger, suction the slurry. Suction hose & Armored hose with HB steel ring in, suitable for limestone, granite, coral, and mineral etc.
Advantages
  • High Abrasion Resistance
  • Light Weight
  • Oil and Heat Resistant
  • Flexible, easy to bending
Dimensions
Inner Diameter (mm) Working Pressure (Mpa) Burst Pressure (Mpa) Length (m) Wall Thickness (mm)
300 0.4-1.2 3.6 1-3 34-37
414 0.4-1.2 3.6 1-3 35-37
560 0.4-1.2 3.6 2-3 40-45
600 0.4-1.2 3.6 2-3 40-45
700 0.8-1.5 4.5 2-3 40-45
800 1.2-2.5 5.5 2-3 50-52
900 1.5-2.5 7.5 2-3 55-58
1000 2.0-2.5 7.5 3-5 75-78
Thermal Shock Resistant Ceramic Hose EC1935 Compliant Mining Hose
Key Features
  • Superior Abrasion Resistance: Alumina ceramic lining provides 10x longer service life than standard hoses in abrasive applications.
  • Extreme Temperature Tolerance: Withstands continuous operation from -60°C to 800°C (peaks to 1200°C).
  • Chemical Inertness: Resists all acids, alkalis, and solvents including HF up to 40% concentration.
  • Explosion Proof Design: ATEX/IECEx certified with conductive lining for hazardous area compliance.
Applications
  • Cement Raw Meal Pneumatic Transport: Abrasion-proof for limestone/clay powders
  • Kiln Exhaust Ducts: Endures 800°C dusty gases with minimal buildup
Why Choose Hongruntong Marine?
  • Value Added Services: On-site installation supervision and maintenance training
  • Material Science Expertise: 15 material engineers continuously developing new composites
  • Cost Effective Solutions: 30% lower TCO (Total Cost of Ownership) than competitors
  • Strategic Partnerships: Preferred supplier to 7 Fortune 500 industrial companies
Frequently Asked Questions
1. How about your delivery time?
Generally, it will take 20 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
2. What are your terms of price?
EXW, FOB, CFR, CIF, DDU.
3. What is your sample policy?
Usually the sample is free of charge, but the customers have to pay for the freight charge.
4. What is your payment term?
1. T/T 30% in advance, and 70% before delivery or against a copy of documents.
2. L/C at sight.
5. Do you have a quality certificate?
Yes, we have ISO, SGS, CE, and related test reports.
