High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-CH69
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
China
MOQ :
1
Price :
USD60 to USD960 Per Piece
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
2630 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Name :
Ceramic Hose
Hose Size :
DN80–1500 (3–60”) as standard
Hose Length :
Up to 20m (66') as standard
Pressure Rating :
-100kPa to +5000kPa (-14.5psi to +725psi) Higher on request
Material :
Rubber and Ceramic
Reinforcement :
Synthetic fabric and wire helix
Outer Cover :
UV, ozone, and abrasion-resistant rubber
Temperature :
30°C to +75°C
Safety Factor :
4:1 as standard
Application :
Transport tailing slurry & abrasive ore particle
Color :
Black
Description
High Pressure Ceramic Inner Rubber Hose Anti Corrosion For Mine Tailings Pump Delivery
Product Overview

Ceramic Hose is an industrial conveying component engineered for corrosive and abrasion-intensive mineral processing environments, particularly in nickel ore beneficiation and hydrometallurgical slurry transport systems. The product features a composite architecture with a chemically resistant elastomer matrix reinforced with high-strength fiber layers and an internal ceramic wear lining system.

Case Study: Nickel Processing Plant - Sulawesi, Indonesia

Implemented in a large-scale nickel ore processing facility in Indonesia's Sulawesi mining corridor, this project addressed challenges of high abrasion and chemical aggressiveness in slurry transport systems. The ceramic hose solution demonstrated improved resistance to both chemical corrosion and mechanical erosion, reducing maintenance frequency and improving system uptime.

High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
Technical Specifications
Parameter Specification
Name Ceramic Hose Pipe
Tube NR, BR, SBR
Reinforcement High Tensile Steel Wire Spiral
Cover NR, CR
Working Pressure < 25 Bars
Flange Material Q235B carbon steel paint
Working Temperature -30℃ to +80℃
Safety Factor 5:1
Application Installed between pump and cutter of dredger, suctioning slurry. Suitable for limestone, granite, coral, and minerals.
Advantages High abrasion resistance, light weight, oil and heat resistant, flexible and easy to bend
Dimensional Specifications
Inner Diameter (mm) Working Pressure (Mpa) Burst Pressure (Mpa) Length (m) Wall Thickness (mm)
300 0.4-1.2 3.6 1-3 34-37
414 0.4-1.2 3.6 1-3 35-37
560 0.4-1.2 3.6 2-3 40-45
600 0.4-1.2 3.6 2-3 40-45
700 0.8-1.5 4.5 2-3 40-45
800 1.2-2.5 5.5 2-3 50-52
900 1.5-2.5 7.5 2-3 55-58
1000 2.0-2.5 7.5 3-5 75-78
Product Highlights
Chemically Resistant Ceramic Barrier Lining System

Internal flow channel features chemically inert alumina ceramic segments that provide resistance to acidic and chloride-containing slurry media, preventing direct chemical interaction between process fluids and elastomer structure.

Dual-Mechanism Wear Protection Architecture

Integrates both abrasion resistance and chemical resistance mechanisms within a single composite structure for balanced performance under combined loading conditions.

Reinforced Structural Stability

Multi-layer reinforcement system maintains dimensional stability under continuous exposure to chemically active slurry, preventing localized deformation.

Optimized Internal Flow Channel Engineering

Internal geometry minimizes turbulence formation and localized chemical stagnation zones, improving hydraulic efficiency and reducing uneven wear patterns.

Applications
  • Nickel Ore Leaching and Slurry Transport Systems
  • Chemical-Exposed Mineral Transfer Points
  • Industrial Waste Slurry Handling Systems
Why Choose Hongruntong Marine
  • Specialized Composite Material Engineering Capability
  • Advanced Process Compatibility Engineering
  • Industrial Quality Assurance and Performance Testing System
  • Global Mineral Processing Project Experience
Frequently Asked Questions
How does Ceramic Hose perform in acidic slurry environments?

The ceramic lining provides a chemically inert barrier that significantly reduces direct exposure of elastomer materials to acidic media, improving structural stability in corrosive environments.

Can this hose handle combined abrasion and chemical corrosion simultaneously?

Yes, the composite structure is specifically engineered to manage dual degradation mechanisms by separating abrasion resistance and chemical resistance functions within the material system.

Is the hose suitable for continuous nickel ore processing operations?

The design supports continuous-duty operation in hydrometallurgical systems where slurry composition and flow conditions remain constant over extended production cycles.

What is the recommended operating temperature range?

The hose is designed for standard industrial mineral processing temperature ranges, maintaining structural integrity under typical hydrometallurgical operating conditions.

Can custom chemical resistance levels be engineered?

Yes, material formulation and ceramic lining configuration can be adjusted based on specific slurry chemistry and process requirements.

High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery High Pressure Anti Corrosion Abrasion Resistant Ceramic Hose for Mine Tailings Pump Delivery
