Customized Cutter Suction River Dredging Equipment With Dredging Depth 15m
Customized Cutter Suction River Dredging Equipment With Dredging Depth 15m
Customized Cutter Suction River Dredging Equipment With Dredging Depth 15m
Customized Cutter Suction River Dredging Equipment With Dredging Depth 15m
Specifications
Brand Name :
JIN MENG
Model Number :
JMD550
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
$300000-$800000
Payment Terms :
T/T
Supply Ability :
10sets/year
Delivery Time :
30days
Packaging Details :
Bulk
Solid Capacity :
700m3/h
Product Type :
River dredger
Suction Pipe Diameter :
600mm
Model :
JMD550
Cutter Head Power :
200KW or customized
Discharge Pipe Diameter :
550mm
Discharge Distance :
2500m
Spud Length :
21m
Power :
1662KW
Application :
River Dredging
Description
Cutter Suction River Dredging Equipment With Dredging Depth 15m Newly Made In Stock
Product Specifications
Attribute Value
Solid Capacity 700m³/h
Product Type River dredger
Suction Pipe Diameter 600mm
Model JMD550
Cutter Head Power 200KW or customized
Discharge Pipe Diameter 550mm
Discharge Distance 2500m
Spud Length 21m
Power 1662KW
Application River Dredging
Company Introduction

Weifang Jin Meng Dredger Co.,Ltd. located in Qingzhou, Weifang City, is a leading manufacturer and supplier of cutter suction river dredgers since 2000. Our products are competitively priced and widely used across Africa, the Middle East, Southeast Asia, South America, and the United States.

Recognized for our technical expertise, high-quality dredgers, and excellent after-sales service, we have established import/export departments, research institutes, and international service offices to better serve our customers.

Our company features:

  • Professional R&D department and CAD design center
  • Dedicated quality control and after-sales service teams
  • Over 200 employees including 3 senior engineers, 8 designers, 5 quality control engineers, and 10 service engineers
Product Features and Applications

The JMD550 Cutter Suction River Dredger features:

  • Horizontal shifting devices
  • Cutter ladder lifting devices
  • Spud devices and deck crane
  • Optional anchoring poles and trolley devices
  • Dredging, conveying, and discharging capabilities for mud and sand
  • Vacuum generation through centrifugal pump
Technical Specifications
Dredging Pump Discharge pipe diameter: 550mm
Head 65m
Max. Working Capacity 900m³/h
Discharge Distance 3000m
Dredging Depth 14m
Diesel Engine 1306KW (Cummins)
Hydraulic Auxiliary Engine 336KW (Cummins)
Emergency Generator 20KW (WEICHAI)
Total Power 1662KW
Oil Consumption 250L/H
Hull Dimensions LOA×W×D: 42m×7.5m×2.0m
Hydraulic System VICKERS America (Joint-venture)
Hydraulic Motor Italy SAI technology (Joint-venture)
Valves REXROTH Germany (Joint-venture)
Operating System SIEMENS PLC (Imported from Germany)
Ladder Winch Tension 120KN
Swing Winch Tension 120KN
Cutter Head Crown-like Φ1800mm, Power: 200KW
Additional Services
  • Skilled workers & ex-work testing: Each dredger undergoes strict quality control and testing before delivery
  • Assembly & Staff Training: Our experienced installers provide on-site guidance and training until operators are proficient
