200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Specifications
Brand Name :
Jin Meng
Model Number :
JMD550
Place Of Origin :
China
Certification :
ISO
MOQ :
1 Set
Price :
$500000-$800000
Packaging Details :
Bulk
Delivery Time :
30days
Payment Terms :
TT
Supply Ability :
20sets/year
Total Power :
1662kw
Maximum Dredging Depth :
14m
Dredge Pump Capacity :
4000m3/h
Suction Diameter :
Up To 600 Mm
Warranty :
1 Year
Sand Pump Brand :
Shijiazhuang Industrial Factory
Dredge Type :
Cutter Suction Dredger
Discharge Diameter :
Up To 550 Mm
Description
200kw Cutter Head Power Diesel Dredgers for Dredging in Canals and Channels
Attribute Value
Total Power 1662kw
Maximum Dredging Depth 14m
Dredge Pump Capacity 4000m3/h
Suction Diameter Up To 600 Mm
Warranty 1 Year
Sand Pump Brand Shijiazhuang Industrial Factory
Dredge Type Cutter Suction Dredger
Discharge Diameter Up To 550 Mm
Diesel Dredgers Description

Our diesel dredgers are versatile and powerful machines designed for demanding dredging applications. Equipped with high-capacity dredge pumps and large cutter suction systems, these dredgers excel in various projects including river dredging, sand mining, and land reclamation.

The 4000m3/h dredge pump capacity enables efficient movement of large material volumes, while the 1.8m cutter diameter effectively handles tough dredging conditions for maximum productivity.

The dredger features a modular design with dismantle-and-box structure hull, allowing easy transportation by road, rail, or container. The power system can be configured as electric or diesel-driven to meet specific requirements.

Key Features
  • Product Name: Diesel Dredges
  • Total Power: 1662kw
  • Dredge Cutter Diameter: 1.8m
  • Control: SIEMENS PLC
  • Suction Diameter: Up To 600mm
  • Testing: Empty Running Before Ex-factory
JMD550 Diesel Dredger Technical Parameters
Dredging Pump Dia. Discharge pipe: 550mm
Head 65m
Max. Working capacity 900m3/h
Discharge distance 3000m
Dredging depth 14m
Diesel Engine 1306KW | Cummins
Hydraulic Auxiliary engine 336KW | Cummins
Emergency Generator 20KW | WEICHAI
Total power 1662KW
Oil Consumption 250L/H
Hull Dimension LOA*W*D: 42m×7.5m×2.0m
Applications

Ideal for various dredging scenarios including:

  • River and channel dredging
  • Port and harbor maintenance
  • Land reclamation projects
  • Sand mining operations
  • Desilting lakes and reservoirs

Effective in diverse soil conditions including hard sand, sludge, clay, and marine sediments.

Customization Options

We offer comprehensive customization services including:

  • Anchor boom configurations
  • Spud carriage systems
  • Additional underwater dredging pumps (20-30m depth capability)
  • Booster stations for extended discharge distances
  • Hydraulic driving systems for safe water transport
Support and Services

Our comprehensive support package includes:

  • On-site installation guidance by experienced engineers
  • Operator training programs
  • 10-15 day installation and testing period
  • Performance testing in actual working conditions
  • Remote technical support
Packaging and Shipping

All dredgers are securely packaged for safe transportation with:

  • Sturdy protective packaging
  • Ample padding materials
  • Tracked shipping services
  • Timely delivery commitments
Product Gallery
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Manufacturing Facility
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
JMD550 in Operation - Maldives Project
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Dredger Close-up View
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
On-site Operation
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Cutter Head Installation
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Dredging Operation
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Inventory Ready for Delivery
200kw Cutter Head Dredgers Equipment Canals And Channel Dredger
Dredger Profile View
