3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
Specifications
Brand Name :
JIN MENG
Model Number :
JMD500
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
$500000-$800000
Payment Terms :
T/T
Supply Ability :
10sets/year
Delivery Time :
30days
Packaging Details :
Bulk
Name :
Sea Dredging Cutter Dredger
Type :
Cutter suction dredger
Fuel Consumption :
183liters/hour
Pump Type :
Centrifugal
Cutter Head Power :
200kW
Cutter Head Diameter :
1800mm
Dredging Capacity :
Up to 600m3/h
Dredging Depth :
Up to 14 meters
Spud Diameter :
300-600mm
Power Source :
Diesel engine
Description
3500m³ 20inch Sea Dredging Cutter Dredger For Sand Reclamation
Product Specifications
Name Sea Dredging Cutter Dredger
Type Cutter suction dredger
Fuel Consumption 183 liters/hour
Pump Type Centrifugal
Cutter Head Power 200kW
Cutter Head Diameter 1800mm
Dredging Capacity Up to 600m³/h
Dredging Depth Up to 14 meters
Spud Diameter 300-600mm
Power Source Diesel engine
Product Overview
The 3500m³ 20inch Sea Dredging Cutter Dredger is a high-performance sand reclamation solution powered by diesel. Designed for efficiency and durability, this cutter suction dredger is ideal for various dredging operations in inland waterways and coastal areas.
Manufacturer Profile
Weifang Jin Meng Dredger Co., Ltd., located in Qingzhou, Shandong Province, China, has been specializing in sea dredging cutter dredger manufacturing since 2000. Our products are known for their competitive pricing, innovative design, and reliable quality, serving markets across Africa, the Middle East, Southeast Asia, South America, and the United States.
Technical Specifications
Dredging Pump WARMAN
Discharge Pipe Diameter 500mm
Head 65m
Max. Working Capacity 700m³/h
Discharge Distance 2500m
Dredging Depth 14m
Diesel Engine 895KW Cummins
Hydraulic Auxiliary Engine 336KW Cummins
Emergency Generator 20KW WEICHAI
Total Power 1213KW
Oil Consumption 183L/H
Hull Dimensions (L×W×D) 42m × 7.5m × 2.0m
Hydraulic System Components VICKERS (USA), SAI (Italy), REXROTH (Germany)
Operating System SIEMENS PLC (Germany)
Cutter Head Φ1800mm Crown-like, 200KW Power
Key Features
  • Designed for dredging operation of soil types II-IV including fine sand, clay, silt, and coarse sand
  • Modular hull design composed of five pontoons for easy transportation and assembly
  • Equipped with diesel engine-driven dredge pump and harbor generator
  • Includes complete pipeline system for solid discharging work
  • Optional pipe materials: Steel, HDPE, or self-floating pipes
Product Gallery
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
3500m3 20inch Sea Cutter Suction Dredger For Sand Reclamation Driven By Diesel Power
