Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Specifications
Brand Name :
JIN MENG
Model Number :
JMD550
Certification :
ISO9001
Place of Origin :
China
MOQ :
1set
Price :
$500000-$800000
Payment Terms :
T/T
Supply Ability :
10set/year
Delivery Time :
30days
Packaging Details :
Bulk
Name :
Sea sand reclamation China river dredger
Type :
Cutter suction river dredger
Suction Pipe Dia :
600 mm
PLC :
SIEMENS
Water Flow :
4000m3
Position Way :
Hydraulic Spud or Spud Carriage
Colour :
customized
Sand Pump Brand :
Shijiazhuang Industrial Factory
Discharge Distance :
Up to 2000m
Hydraulic Winch :
Xinhong Brand
Description
Sea Sand Reclamation China River Dredger Boat With Cutter Head
Product Specifications
Attribute Value
Name Sea sand reclamation China river dredger
Type Cutter suction river dredger
Suction Pipe Diameter 600 mm
PLC SIEMENS
Water Flow 4000m³
Position Way Hydraulic Spud or Spud Carriage
Colour Customized
Sand Pump Brand Shijiazhuang Industrial Factory
Discharge Distance Up to 2000m
Hydraulic Winch Xinhong Brand
Company Introduction

Weifang Jin Meng Dredger Co., Ltd., located in Qingzhou, Weifang City, is a professional manufacturer specializing in sand reclamation China river dredgers, work boats, and gold dredging equipment. Our company focuses on research, design, production, and sales of high-quality dredging solutions.

We maintain a professional R&D department, CAD drawing design center, quality control department, and after-sales service team. With over 500 employees, our team includes:

  • 5 professional senior engineers specialized in dredger building and research
  • 16 machinery construction designers
  • 8 quality inspection and control engineers
  • 10 after-sales service engineers
Product Description

Our sand reclamation China river dredgers are designed, constructed, and inspected according to CCS standards and regulations. Key features include:

  • CCSB steel plates meeting CCS requirements
  • Skilled, experienced welders certified under CCS regulations
  • Marine-grade anti-corrosion painting materials
  • Cummins or MITSUBISHI diesel engines (American/German technology)
  • Shijiazhuang pumps with Kinda technology
  • Hangzhou Advance Gearbox (China famous brand)
  • Rexroth hydraulic system (German technology)
  • SIEMENS PLC system (German technology)
  • NSK bushes/shaft sleeves (Japanese technology)
  • Parker sealings (American technology)
Product Functions

Our dredgers are designed for multiple applications:

  • Dredging rivers and sand
  • Desilting operations
  • Land and channel reclamation
  • Road construction projects

Suitable working environments include seas, ports, lakes, and rivers. Capable of handling various soil conditions including hard soil, hardened sand, sludge, sea sand, river sand, clay, and mud.

Technical Specifications: JMD550 Model
Dredging Pump Shijiazhuang
Discharge Pipe Diameter 550mm
Head 65m
Max. Working Capacity 900m³/h
Discharge Distance 3000m
Dredging Depth 14m
Diesel Engine 1306KW Cummins
Hydraulic Auxiliary Engine 336KW Cummins
Emergency Generator 20KW WEICHAI
Total Power 1662KW
Oil Consumption 250L/H
Hull Dimensions (LOA×W×D) 42m × 7.5m × 2.0m
Hydraulic System Components VICKERS pump (America), SAI motor (Italy), REXROTH valves (Germany)
Operating System SIEMENS PLC (Germany)
Ladder Winch Tension 120KN
Swing Winch Tension 120KN
Cutter Head Φ1800mm crown-like, 200KW power
Customization Options

Our sand reclamation China river dredgers can be customized to meet specific requirements:

  • Anchor booms installation
  • Spud carriage configuration
  • 5-anchor positioning system
  • Hydraulic driving for spud flat down for safe water transport
  • Dual underwater dredging pumps for 20-30m depth operations (>30% slurry concentration)
  • Booster station for extended discharge distance
Product Gallery
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model
Sea Sand Reclamation River Dredger Machine With Cutter Head JMD550 Model

For more information about our sea sand reclamation China river dredgers or to discuss customization options, please contact our sales team.
