Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Specifications
Brand Name :
JIN MENG
Model Number :
JMD550
Certification :
ISO9001
Place of Origin :
China
MOQ :
1set
Price :
$300000-$800000
Payment Terms :
T/T
Supply Ability :
10sets/year
Delivery Time :
30days
Packaging Details :
Bulk
Name :
Sea sand dredger with cutter head
Type :
Cutter suction dredger
Function :
Sea sand dredging
Water flow :
4000m3
Max. dredging depth :
15m
Discharge distance :
2000m
Diesel engine :
Cummins
Dredging pump :
Shijiazhuang
Description
Hydraulic Cutter Suction Dredger With Cutter Head For Sea Sand Dredging
Attribute Value
Name Sea sand dredger with cutter head
Type Cutter suction dredger
Function Sea sand dredging
Water flow 4000m³
Max. dredging depth 15m
Discharge distance 2000m
Diesel engine Cummins
Dredging pump Shijiazhuang
About Weifang Jin Meng Dredger Co., Ltd.

Weifang Jin Meng Dredger Co., Ltd. is a reliable sand dredger supplier located in Qingzhou, Weifang City, Shandong Province. Specializing in sea dredging sand dredger machine manufacturing since 2000, our products offer excellent price advantages and serve markets across Africa, the Middle East, Southeast Asia, South America, and the United States.

Product Description

Our sea dredging sand dredgers are available in self-propelled or non-self-propelled, portable configurations. The hull features a dismantle and box-like structure, allowing for easy assembly at the worksite and transportation via road, railway, or container. The power system can be customized to electric or diesel engine driving systems based on customer requirements.

Key equipment includes:

  • Traversing device
  • Cutter ladder lifting device
  • Spuds and deck crane
Technical Specifications
Dredging Pump WARMAN
Discharge pipe diameter 550mm
Head 65m
Max. working capacity 900m³/h
Discharge distance 3000m
Dredging depth 14m
Diesel Engine 1306KW Cummins
Hydraulic Auxiliary engine 336KW Cummins
Total power 1662KW
Hull dimensions (LOA×W×D) 42m × 7.5m × 2.0m
Features and Applications

Our sea sand dredger can easily pass under low bridges, with dismountable control and rest rooms. The construction consists of three pontoons (one main and two side pontoons) connected by high-intensity bolts and nuts.

Suitable working sites: sea, port, lake, and river environments.

Soil conditions: hard soil, hardened sand, sludge, sea sand, river sand, clay, mud, and similar materials.

Customization Options

The sea sand dredger can be customized according to specific requirements:

  • Anchor booms installation
  • Spud carriage
  • Dredger position with 5 anchors
  • Hydraulic driving for spud flat down
  • Additional dredging pump for increased depth (20-30m underwater)
  • Booster station for extended discharge distance
Product Gallery
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Cummins Engine Hydraulic Cutter Suction Dredger Equipment 4000m3
Contact us for more details about our sea sand dredgers and customized solutions.
