EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Pixel Pitch :
10 mm
LED Type :
DIP346
LED Chip :
EPISTAR
Module Size :
160 × 160 mm
Cabinet Dimension :
960 × 960 mm
Weight :
41 kg/pc
Screen Size :
3.84 × 2.88 m
Control Method :
Synchronization
Description

EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof

Quick Detail:

1. DIP346 LED type;
2. 6 × 6 pcs LED modules per cabinet;
3. 960 × 960 mm cabinet size;
4. 4 × 3 pcs cabinets in total;
5. Chuanglian brand power supply;
6. LINKO / YZK power and signal connector.

Detail Description:

This is DIP346 LED type, with more than 6500 nits, 960 by 960 mm cabinet size;
Each cabinet with 1 pc NOVA receiving card, to achieve high refresh rate;
36 pcs LED modules in a cabinet, with 4 pcs power supplies, each 5V 40A.

Application:

P10 outdoor advertising LED display is hot selling type, for video advertising, commercial ads, ect.

Specifications:

Type

PH10

LED Type

DIP346

LED Composition

1R 1G 1B

Screen Size

W 3.84 × H 2.88 m

Screen Resolution

W 384 × H 288

LED Module Size

W 160 × H 160 mm

Cabinet Size

W 960 × H 960 × D 145 mm

Cabinet Weight

41 kg/pc

Material

Steel waterproof cabinet with back door

LED Module Quantity

W 24 × H 18 = 432 pcs

Cabinet Quantity

W 4 × H 3 = 12 pcs

Refresh Rate

≥1000Hz

Driving Method

1/4 scan constant current

Brightness

6500 nits/sq.m

Viewing Angle

100 degrees

Warranty

2 years

Power Supply

220V / 60HZ

Brand

Chuanglian

Controller

Novastar

Package

Plywood case


EPISTAR 6500 nits 10mm Outdoor Full Color Led Display DIP346 LED Waterproof

Outdoor Waterproof LED Display, 10 mm Outdoor LED Display Screen, Outdoor Full Color LED Display
