Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Synchronization Control 16 mm Perimeter LED Display with Video Processor
Specifications
Brand Name :
Dreamway
Model Number :
P16
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Flight case
Description



Synchronization Control 16 mm Perimeter LED Display with Video Processor


Quick Detail:

1. EPISTAR LED chip;
2. JXI5020 IC;
3. More than 7500 nits;
4. NovaStar LED controller;
5. VMS736 video processor;
6. Soft LED module mask.


Detail Description:

We use Novastar controller to operate, with high refresh rate and easy control;
The LED module mask is soft, with support at the back and protect cover above the cabinet;
2 years quality guarantee provided.


Application:

This type perimeter LED display is installed in soccer stadium for advertising, with synchronous control.


Specifications:

Pixel Pitch

16 mm

Resolution

3,906 dots/sq.m

LED Chip

EPISTAR

Drive IC

JXI5020

LED Module Pixel

W 16 × H 16

LED Module Size

W 256 × H 256 mm

Cabinet Material

Steel cabinet, with support standing and protect cover

Drive Method

Static scan

Luminance

More than 7500 nits/sq.m

Refresh Rate

1200~4000 Hz

Out of Control Dot Rate

＜0.0001

Earth Leakage Current

＜2mA

MTBF

＞5,000 hours

Life Span

＞100,000 hours

Power Source

110V/60HZ and 220V/50HZ interchangeable

Connector

YZK

Control Method

Synchronous control with PC and video processor

Package

Flight case


Synchronization Control 16 mm Perimeter LED Display with Video Processor
