High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision
Specifications
Brand Name :
Dreamway
Model Number :
P10
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000sq.m/Month
Delivery Time :
20 days after receiving the deposit
Packaging Details :
Plywood case
Model :
PH10
LED Type :
SMD3535
LED Module Pixel :
32 × 16 dots
LED Module Size :
320 × 160 mm
Cabinet Size :
640 × 1120 mm
Material :
Iron waterproof cabinet with back door
Screen Size :
12.8 × 2.24 m
Resolution :
1280 × 224 pixels
Description



High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision


Quick Detail:

1. 1/2 scan constant current;
2. About 6,500 nits;
3. SMD3535 LED;
4. 12.8 × 2.24 m screen size;
5. 1280 × 224 screen resolution;
6. 320 × 160 LED module pixel.


Detail Description:

This P10 LED display is with 6,500 nits, 1/2 scan, SMD3535 type;
The total screen size is 12.8 m length, 2.24 m height;
It is controlled by synchronization, Novastar, with high refresh rate.


Application:

Outdoor LED display is used to show videos, pictures, text, etc, for outdoor public places. It could bring big profit for advertising.


Specifications:

Pixel Pitch

10 mm

LED Type

SMD3535

LED Composition

1R 1G 1B

Screen Size

W 12.8 × H 2.24 m

Resolution

W 1280 × H 224 pixels

LED Module Size

W 320 × H 160 mm

Cabinet Size

W 640 × H 1120 × D 150 mm

Cabinet Weight

29 kg/pc

Material

Iron waterproof cabinet with back door

LED Module Quantity

W 40 × H 14 = 560 pcs

Cabinet Quantity

W 20 × H 2 = 40 pcs

Best Viewing Distance

10 ~ 70 m

Driving Method

1/2 scan constant current

Brightness

6,500 nits

Viewing Angle

120 degrees

Power and Signal Connector

Linko

Power Supply

88 ~ 264VAC

Brand

Meanwell

Control Card

Novastar

Warranty

2 years


High Resolution 1/2 Scan Outdoor Advertising Led Display Panel Super Clear Vision

P10 Outdoor SMD LED Display, Outdoor Video LED Display, Outdoor LED Display Screen of 10 mm
