DIP OPTO / SILAN P20 Outdoor Advertising LED Display Static Scan , 320×160 mm module
DIP OPTO / SILAN P20 Outdoor Advertising LED Display Static Scan , 320×160 mm module
DIP OPTO / SILAN P20 Outdoor Advertising LED Display Static Scan , 320×160 mm module
DIP OPTO / SILAN P20 Outdoor Advertising LED Display Static Scan , 320×160 mm module
Specifications
Place of Origin :
China
Brand Name :
Dreamway
Certification :
CE,ROHS
Model Number :
P20
MOQ :
negotiable
Price :
negotiable
Packaging Details :
Plywood case
Delivery Time :
20 days after receiving the deposit
Payment Terms :
T/T
Supply Ability :
2000sq.m/Month
Description



OPTO / SILAN P20 Outdoor Advertising LED Display with Static Scan


Quick Detail:

1. OPTO / SILAN LED;
2. 2,500 dots/sqm;
3. R9 GB10×12 chip size;
4. MBI5024 driving IC;
5. 320×160 mm module size;
6. More than 6000 nits/sq.m.


Detail Description:

Power supply is 110V/60HZ and 220V/50HZ convertible, with CE standard;
Control PC operates with the display simultaneously;
Long distance like 10km could be achieved by using optical fiber.

Specifications:

Pixel Pitch

20mm

Pixel Composition

2R1G1B

LED Encapsulation

DIP546

Pixel

2,500 dots/sq.m

Module Pixel

W 16 × H 8

Module Size

W 320 × H 160 mm

Standard Cabinet Size

W 1280 × H 960 mm

Cabinet Color

Black

Cabinet Material

Steel waterproof

Drive Method

Static scan

Brightness

≥6000 nits/sq.m

Refresh Rate

≥800Hz

Out of Control Dot Rate

＜0.0001

Earth Leakage Current

＜2mA

MTBF

＞5,000 hours

LED Life Span

＞100,000 hours

Power Supply

110V/60HZ and 220V/50HZ interchangeable

Humidity

10%~90%

Control Method

Synchronous control with PC on

Operation System

Win2000 / XP / Vista

P20 Outdoor Advertising LED Display, Large Outdoor Advertising LED Display, Advertising LED Display for Outdoor Use
