Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing
Specifications
Brand Name :
XENTER
Model Number :
XT-FCDYX-15W/20W
Certification :
BIS CE RoHS IP65
Place of Origin :
China
MOQ :
500pcs
Supply Ability :
5000pcs/day
Delivery Time :
25-30 days
Packaging Details :
color box, standard export carton
Luminaire Type :
Bulkhead Lights
Watt :
15 watt
Light Source :
LED SMD2835
Colour Temperature :
Daylight , Natural Light, Warm Light
Housings :
PP Base + PP Diffusor
Accessories :
Metal Bracket , Screws
Luminous Efficieny :
90-100lm/w
IP Rating :
IP65
Warranty :
1 year
Beam Angel :
120º
Lumens :
1670lms
Integrated LED Driver :
Yes
PCS/CTN :
40pcs
CTN Size(cm) :
50*37*46cm
Type :
Wall Bracket Light Fitting
Description

IP65 Bulkhead Lights Outdoor Oval Luminaire Moistureproof Wall Ceiling Oval 15W

Product Description
70% Energy Savings , 90% Maintenance Savings
Wattage 15W
Operating Temp -20°C to 50°C
Housing PP (PC) + PP Diffuser
Beam Angle : 120°
Lumens per Watt : 90-100lm/w
CRI: >70Ra
IP Rating : IP65
Warranty: 1 year
Finish : Black / White
Dimensions 214*112*69mm
This surface-mounted outdoor LED Bulkhead luminaire (IP65) has been designed to provide rugged performance, White / black trim to match most fascias, guttering and facades – this can be either wall or ceiling-mounted to enhance exterior communal spaces , or as the main security/comfort lighting in residential and commercial exterior applications.
These LED bulkheads are waterproof to IP65 plus anti-corrosive , making them additionally suitable for coastal environments. the bulkhead is available in Daylight and Natural White.
Suitable for offices, warehouses, retail, leisure, car parks, education, healthcare, amenity, logistics and transportation.

15W /20W Oval Wall / Ceiling Light Specifications

Model No. XT-FCDTY-15W / 20W
Product Type Surface
Bulkhead Shape Round
Dimmension (mm) 214*112*69 / 270*143*78
Voltage Rating AC170-300V
Light Source LED 2835 SMD
Rated Wattage 15W /20W
Metal Bracket Yes
Luminous Efficency 90-100lm/w
Output Colour 3000K 4000K 6500K
Work Frequency 50/60Hz
Power Efficiency >95%
Power Factor >0.5
CRI Ra>70
Beam Angle 120° - 140º
Finish Colour Black / White
Housing Materials Diffuser:PP / Base:PP / Metal Bracket
IP Rate IP65
Working Temperature -20℃ to +60℃
Working Humidity 10-70% RH
Dimmable No
Guarantee 1 year
Certificate IP65 CE RoHS BIS
Application Indoor / Outdoor Lighting
PCS/CTN 40pcs / 20pcs
CTN Size 50*37*46 cm / 62*42*29.5 cm

Outdoor Oval Luminaire Moistureproof Bulkhead Wall Light 15W PP Base + PP Diffusor Housing


Lighting Application

Perfect for interior wall and exterior wall and ceiling lighting , ideal lighting for Tunnels , Parkinig lots , the Subway Stations , Workshops , Corridors , Community , Bath Rooms , Bed Rooms , Dinning Rooms , Restaurants , Office , Kitchen , Hallway , Utility , Staircase , Garden , Countyard , Bus Station , Shed , Patio , Car Washing Stations etc.


Warnings

1. Cut off the power before installation
2. Cant be used as emergency light
3. To keep them away for the flammable objects.
4. The environment temperature of the lamp operation: -20Ċ to +60Ċ
5. Do not try to open this unit , they are sealed completely
6. To install it by professional electrician
