128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized
128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized
128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized
128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized
Specifications
Brand Name :
STATEMED
Model Number :
STT2-CDU32
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
competitive
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 sets per month
Delivery Time :
10 working days
Packaging Details :
carton, wooden case
Type :
Doppler Ultrasound Equipment
Imaging mode :
Free-hand 3D
Specialty ode :
Cardiac
Function :
3D Ultrasound scanner
Scanning mode :
Trans vagina
Display Mode :
B/M
Warranty :
15 months
Image magnification :
Picture in picture zoom in and zoom part function
Description

128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized

Performance requirements in grayscale imaging mode

Color ultrasound in the gray scale imaging mode of the performance of the probe:

Performance Probe type and nominal frequency
2.0≤f＜5.0 5.0≤f＜8.0 5.0≤f＜10.0
a) Robe type, model Convex array (model TC60A) Cavity (model TC10A) Line array (model TL40A)
b) Robe nominal frequency (MHz) 3.5 5.5 7.5
c)Robe depth(mm) ≥160 ≥80 ≥50
d) Lateral resolution (mm)

≤3(depth≤80)

≤4(80＜depth≤130)

 ≤2(depth≤40) ≤2(depth≤40)
e) Axial resolution (mm)

≤2(depth≤80)

≤3(80＜depth≤130)

 ≤1(depth≤40) ≤1(depth≤50)
f) Blind zone (mm) ≤5 ≤5 ≤3
g) Horizontal geometric position accuracy (%) ≤15 ≤20 ≤10
h) Longitudinal geometric position accuracy (%) ≤10 ≤10 ≤5
i) Slice thickness (mm) ≤7 ≤5 ≤5
j) Perimeter and area measurement deviations (%) ≤±20 ≤±20 ≤±20
k) M mode time display error (%) ≤±10 ≤±10 ≤±10

128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized

Transport:

128 E Diagnostic Baby Color Doppler Ultrasound Scanner B / M Display Mode Customized
