OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm
OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm
Specifications
Features :
Adjustable cutting angle, safety guard, dust collection system
Voltage :
220V
Brand Name :
shuping
Model Number :
DZW
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10pcs/40 work days
Delivery Time :
35-40 work days
Packaging Details :
Bubble wrap packaging
Frequency :
50Hz
Blade Diameter :
300mm
Power :
2.2KW
Weight :
120kg
Cutting Angle :
90 degrees
Dimensions :
800mm x 600mm x 1200mm
Application :
Cutting door frames and moldings
Blade Material :
Tungsten Carbide
Cutting Speed :
2800rpm
Price :
$10000-$50000
Cutting Capacity :
Up to 15mm
Power Source :
Electric
Description

CNC Wood Door Saw-Milling Center

OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm

Quality Door Frame Cutting Machine from factory, OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm, $10000-$50000,1 MOQ,China


Technical Parameters

(The equipment is subject to continuous improvement; configurations are for reference only)


Item Parameter
Main Milling Spindle Motor 8 KW (with automatic oil supply, atomized cooling and lubrication)
Motor Power for Lock Milling Spindle 5.6 KW
Motor Power for Hinge Milling Spindle 0.75 KW × 2
Motor Power for Latch Milling Spindle 0.75 KW
Motor Power for Reverse Horizontal Milling 0.75 KW
Motor Power for Lifting Hole Drilling Spindle 0.75 KW × 1
Workpiece Length 2500 mm
Workpiece Width 300–1000 mm
Workpiece Thickness 18–55 mm
Positioning Accuracy ±0.01 mm
Lock Hole Machining Cycle ≤ 60 seconds
QR Code Recognition Speed < 3 seconds
Overall Machine Footprint 4700 × 2500 × 2400 mm


OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm


OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm


OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm


OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm

OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm

OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm

OEM Wood Door Production Line Saw Milling CNC Door Making Machine 2800rpm
