Specifications
Brand Name :
DLX
Model Number :
ni200 Pure Nickel
Place of Origin :
China Jiangsu
MOQ :
2kg
Price :
$20-$300/kg
Payment Terms :
L/C,T/T,Western Union,
Supply Ability :
500 tons per month
Delivery Time :
5-20 Days
Packaging Details :
Spool package with Carton box, Coil package with polybag,
Certification :
CE,ROHS
Product name :
Pure Nickel 200/201
Grade :
200 201 N4 N6
Certificate :
ISO9001
Material :
Ni
Elongation (≥ %): :
35
Ni(min) :
99.94%
Application: :
industry
Melting point :
1435-1445℃
M.O.Q: :
1KG
delivery :
7-25 days
shape :
wire
size :
0.025-10mm
Description
ISO9001 & SGS Certified | Since 2002 | 12,000 m² Factory | 99.9% Ni Wire | 7-15 Day Ship

Overview

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

Low MOQ and samples first: start this 99.9% pure nickel wire with a small order, qualify the material, then scale. The wire pairs low magnetic permeability with high thermal conductivity and excellent weldability — precision-drawn from 0.025 to 10 mm. Nickel content is 99.9% minimum (N4/NP1). For related pure nickel wire options and pure nickel strip for battery use, browse the DLX catalogue. Produced on our own nickel-alloy line, every spool is inspected per batch before packaging.

Dimensions & Tolerances

Parameter Value Note
Diameter range 0.025-10 mm micro wire from 0.025 mm
Tolerance Per drawing / GB/T 21653 exact values per drawing
Continuous length Per order dependent on diameter
Temper Soft / hard / 1/2 hard per drawing
Surface Clean, oxide-free per drawing

MOQ 1 kg (micro wire ≤0.05 mm) / 5 kg (standard wire); samples available before series production.

Key Strengths

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

  • Low MOQ and samples — start small, qualify the material, then scale.
  • Low magnetic permeability — suited to electronics and instrumentation use.
  • High thermal conductivity — 70.2 W/m·K for effective heat transfer.
  • Excellent weldability — compatible with conventional welding, brazing and soldering.
  • 99.9% purity verified per batch — produced on our own line with EN 10204 3.1 documentation on request.

Technical Deep Dive

1. Low Magnetic Permeability

Low magnetic permeability makes the wire suitable for electronics and instrumentation applications where magnetic interference must be minimized. The Curie temperature of 358°C anchors the magnetic transition, and the material's magnetic behaviour is confirmed against the application.

2. High Thermal and Electrical Conductivity

Thermal conductivity of 70.2 W/m·K (Ni200) and electrical resistivity of 0.096 μΩ·m at 20°C place the wire as an effective conductor of both heat and current — the combination demanded in electronic and thermal management applications.

3. Excellent Weldability and Formability

The wire is compatible with conventional welding, brazing and soldering processes, and responds well to hot rolling, cold forming and machining — practical for assemblies that must be joined and shaped.

4. Sample and Low-MOQ Start

Samples and small-batch orders are available before series production, so you can verify diameter, weld response and performance against your process. Once qualified, the same specification carries into production volume.

5. In-House Production and Inspection

Our production process includes melting, drawing, heat treatment, finishing and testing — a full in-house chain. Every spool passes chemical composition analysis, diameter inspection and surface checks before packaging.

Grade & Price Guide

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

Grade Ni Content Best Application Reference Price (FOB, USD/kg)
N4 (NP1) ≥99.9% Vacuum electronics 420-480
Ni201 ≥99.0% High-temp service 350-390
Ni200 ≥99.2% Battery, chemical 340-380
N6 (NP2) ≥99.5% Industrial corrosion 300-340

Reference prices are FOB indicative ranges per grade; final quotation depends on size, quantity and delivery terms.

Chemical Composition

Element (wt%) N4 N6 Ni201 Ni200
Ni+Co 99.9 99.5 — —
Ni — — ≥99.0 ≥99.2
C ≤0.01 ≤0.10 ≤0.02 ≤0.15
Cu ≤0.015 ≤0.10 ≤0.25 ≤0.25
Si ≤0.03 ≤0.10 ≤0.35 ≤0.35
Mn ≤0.002 ≤0.05 ≤0.35 ≤0.35
Fe ≤0.04 ≤0.10 ≤0.40 ≤0.40
S ≤0.001 ≤0.005 ≤0.01 ≤0.01
P ≤0.001 ≤0.002 — —
Mg ≤0.01 ≤0.10 — —

Source: DLX product catalogue; per-batch verification available on request.

Physical & Mechanical Properties

Density 8.908 g/cm³
Melting point 1435-1446°C
Curie temperature 358°C
Tensile strength (annealed) ≥462 MPa
Elongation (annealed) ≥35%
Hardness (annealed) 90-120 HB
Shear modulus ~76 GPa
Electrical resistivity 0.096 μΩ·m (20°C)
Thermal conductivity (Ni200) 70.2 W/m·K

Product Specifications

Form Pure nickel wire
Featured grade N4 (NP1)
Diameter 0.025-10 mm, per drawing
Temper Soft / hard / 1/2 hard per drawing
Surface Clean, oxide-free per drawing
Packaging Spool with carton box, or coil with polybag

Quality Assurance

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

  • Per-batch chemical composition testing with full traceability
  • Diameter and surface inspection per governing standard
  • Per-batch dimensional records against the drawing
  • EN 10204 3.1 material test certificate available with shipment

Applicable Standards

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

Ni200 / Ni201 ASTM B164 (Nickel Rod, Bar and Wire)
N4 (NP1) / N6 (NP2) GB/T 21653 (Nickel and Nickel Alloy Wire and Drawn Wire Billet)

Packaging & Delivery

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications 99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications


Wire is supplied on spools with carton boxes, or as coils with polybags, per order. Lead time: 7-15 days. Material certificates and inspection documents accompany each shipment.

About DLX

99.9% Pure Nickel Wire with Low Magnetic Permeability High Thermal Conductivity and Excellent Weldability for Industrial Applications

Sample first, scale later — that is how high-purity wire earns its place in electronics and instrumentation, where low magnetic permeability matters as much as purity. Changzhou DLX Alloy Co., Ltd. — a 12,000 m² nickel-only plant since 2002, 1,200 tonnes per year, ISO9001 with SGS support — supplies 99.9% N4 wire with low MOQ and samples, drawn in-house, inspected per batch, documented with EN 10204 3.1 on request.

FAQ

Q1: What makes this wire low-magnetic-permeability?

A: The material's magnetic behaviour, anchored by a Curie temperature of 358°C, suits electronics and instrumentation applications where magnetic interference must be minimized.

Q2: Is the 99.9% purity guaranteed?

A: Yes — N4 (NP1) holds Ni+Co of 99.9% or higher, tested per batch with EN 10204 3.1 documentation on request.

Q3: Can I get samples or a trial order first?

A: Yes — samples and small-batch orders are available before series production; shipping at the customer's cost.

Q4: What are the diameter and MOQ?

A: 0.025-10 mm per drawing; MOQ 1 kg for micro wire (≤0.05 mm), 5 kg for standard wire.

Q5: What should I include when requesting a quote?

A: Grade, diameter, temper, quantity, governing standard and destination port — confirmed at quotation. Special packaging available on request.
