NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
NP2 Pure Nickel Wire with Low Vapor Pressure High Thermal Conductivity and Excellent Electrical Resistivity
Specifications
Brand Name :
DLX
Model Number :
ni200 Pure Nickel
Place of Origin :
China Jiangsu
MOQ :
2kg
Price :
$20-$300/kg
Payment Terms :
L/C,T/T,Western Union,
Supply Ability :
500 tons per month
Delivery Time :
5-20 Days
Packaging Details :
Spool package with Carton box, Coil package with polybag,
Certification :
CE,ROHS
Product name :
Pure Nickel 200/201
Grade :
200 201 N4 N6
Certificate :
ISO9001
Material :
Ni
Elongation (≥ %): :
35
Ni(min) :
99.6%
Application: :
industry
Melting point :
1435-1445℃
M.O.Q: :
1KG
delivery :
7-25 days
shape :
wire
size :
0.025-10mm
Description
NP2 Pure Nickel Wire High Purity Diameter 0.025mm (0.001in)

Diameter 0.025mm (0.001in) pure nickel wire NP2 wire from factory.

Pure Nickel Ni200/Ni 201 Wire

Pure nickel NP2 is a high purity nickel product with purity over 99.6%. The 0.025mm NP2 wire is widely used in military, aerospace, medical, chemical, electronic and other industries.

Key Benefits
  • Excellent resistance to corrosive and caustic environments, media, alkalis, and acids (sulfuric, hydrochloric, hydrofluoric)
  • Unique magnetic and magnetostrictive properties
  • High thermal and electrical conductivities
  • Low gas content and vapor pressure
  • Suitable for both indoor and outdoor applications
  • Excellent formability through hot rolling, cold forming, and machining
  • Compatible with conventional welding, brazing, and soldering processes
Chemical Composition
Grade Ni+Co Cu Si Mn C Mg S P Fe
N4/201 99.9 ≤0.015 ≤0.03 ≤0.002 ≤0.01 ≤0.01 ≤0.001 ≤0.001 ≤0.04
N6/200 99.5 0.1 0.1 0.05 0.1 0.1 0.005 0.002 0.1
Size Range

Wire: 0.025 to 8.0 mm.

Physical Data
Density 8.89g/cm³
Specific Heat 0.109 (456 J/kg·℃)
Electrical Resistivity 0.096×10⁻⁶ ohm·m
Melting Point 1435-1446℃
Thermal Conductivity 70.2 W/m·K
Mean Coeff Thermal Expansion 13.3×10⁻⁶ m/m·℃
Typical Mechanical Properties
Mechanical Properties Nickel 200
Tensile Strength 462 MPa
Yield Strength 148 MPa
Elongation 47%
Production Standards
Bar Forging Pipe Sheet/Strip Wire
ASTM B160 ASTM B564 ASTM B161/B163/B725/B751 AMS B162 ASTM B166
Frequently Asked Questions
How can I contact your company?

We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile telephone.

What is your working time?

Monday-Saturday: 8:30AM-16:00PM (Beijing time, GMT+08.00). We have public holidays during May 1-3, Oct 1-7 and Chinese New Year. For details, please see our updated holiday notice.

Do you provide free samples?

Yes, we can provide a free sample for testing. The buyer should bear all shipping costs.

What is your payment terms?

T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal. We do our best to match your demand.

What is the lead time?

Sample lead time is typically 7 days after payment confirmation. Normal orders take 10-30 days depending on quantity. We always strive to deliver high-quality products as quickly as possible.

Can you supply neutral packaging or labels with our company name?

Yes, please confirm your requirements with your RFQ and order. Special packaging to individual requirements may also be available on request.
