AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015
AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015
AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015
AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015
Specifications
Brand Name :
JIAXIN
Model Number :
UL 1015
Certification :
UL/CUL
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100KM/Week
Delivery Time :
7-15 working days
Packaging Details :
Steel wooden drum
Product Name :
AWM 1015
Approval :
RoSH,UL
Packing :
305Meters per roll
Application :
Electrical Wire
Rated Votage :
600V
Conductor Type :
Bare Copper / Coated Copper, Solid or Stranded
Type :
Insulated
Standards Certificates :
UL 758
Description

▼ UL Approved PVC Insulation Electric Cable, AWM Cable ul 1015 18awg wire Cable

1. Datas

Designation AWG No./Wire Conductor Diameter DCR @ 20℃ Insulated Thickness Minimum insulation thickness Insulation Diameter Capacity in air @ 25℃
AWM 1015 20 26/0.16 0.93 34.6 0.76 0.69 2.60±0.15 12
AWM 1015 18 41/0.16 1.18 21.8 0.76 0.69 2.80±0.15 15
AWM 1015 16 26/0.254 1.49 13.7 0.76 0.69 3.10±0.15 21
AWM 1015 14 41/0.254 1.86 8.62 0.76 0.70 3.50±0.15 27
AWM 1015 12 65/0.254 2.34 5.43 0.76 0.71 4.00±0.15 37
AWM 1015 11 83/0.254 2.67 4.3 0.76 0.69 4.30±0.15 43
AWM 1015 10 105/0.254 3.1 3.41 0.76 0.69 4.60±0.20 50
AWM 1015 9 133/0.254 3.81 2.71 0.76 0.69 5.35±0.20 63.0
AWM 1015 8 168/0.254 4.00 2.14 1.14 1.04 6.60±0.25 74.7
AWM 1015 7 133/0.321 4.83 1.7 1.14 1.04 7.20±0.25 85.5
AWM 1015 6 266/0.254 5.43 1.35 1.53 1.37 8.50±0.25 99.0
AWM 1015 5 336/0.254 6.09 1.07 1.53 1.37 9.20±0.25 117.0
AWM 1015 4 420/0.254 6.80 0.85 1.53 1.37 10.00±0.30 135.0
AWM 1015 3 532/0.254 7.10 0.67 1.53 1.37 10.50±0.30 153.0
AWM 1015 2 665/0.254 8.60 0.53 1.53 1.37 11.8±0.30 180.0
AWM 1015 1 836/0.254 9.60 0.42 2.1 1.83 13.50±0.40 207.0
AWM 1015 1/0 1045/0.254 10.85 0.34 2.1 1.83 14.40±0.50 243.0
AWM 1015 2/0 1330/0.254 12.30 0.266 2.1 1.83 16.40±0.50 288.0

2. Advantages

a. Excellent resistance to oil, corrosives, UV etc.

b. Flexible, conviniently to assemble

C. Uniform insulation thickness of wire to ensure easy stripping and cutting

3. Construction

a. Core Conductor: Stranded annealed flexible conductor

b. Popular sizes: 30AWG-4/0AWG

c. Insulation: Flame-retardant PVC

d. Temperature rating: 105℃

e. Approval: UL,ROSH

f. Voltage suitable: 600V

4. Production Application

Usually used in weak current engineering, suitable for general electronic and electrical equipment internal connection lines, wiring for lighting equipment, medical and chemical industries, etc.

AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015

▼ Packing&Delivery:

We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline

is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
The cable is supplied in wooden reels, corrugated boxes, and coils. Cable ends are sealed with BOPP self-adhesive

tape and non-hygroscopic sealing caps to protect the cable end from moisture. The required marking shall be printed

with a weather-proof material on the outsides of the drum according to customers' requirements.

AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015

▼Certifications:

AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015

▼ Delivery Port :

AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015 AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015 AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015
Port of Shenzhen Port of Hongkong

Port of Guangzhou
