Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Specifications
Brand Name :
Dissmann
Model Number :
DFN-E
Certification :
UL
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1,000,000pcs
Delivery Time :
5-8days
Packaging Details :
Standard Carton Packing
Material :
Electric wood shell
Colour :
Red,Yellow,Blue
Rated Voltage :
80VDC
Rated Current :
20A-60A
Breaking Capacity :
DC1KA
Standard :
UL248-13、 ISO8820、ROHS
Usage :
Automotive
Keyword :
Car blade fuse
Description

Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard

Material:
Noumenon:Ceramic
Pins: Alloy

Features:

Pv Inverter Fuse
Many kinds of Pv Inverter Fuse
Current rating: 400A
Voltage rating: 750VDC

Breaking capacity:DC10KA

Product Presentation:

Rated Voltage

80VDC

Characteristic

 Fast Blowing
Rated Current 20A-60A

Breaking Capacity

 DC1000A

Meet the Requirement

UL248-13,ISO8820,

EU and Rosh Directive

Remarks

 UL

Overall dimensions of the product(mm)

Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard

Product type

Model Product code Rated current I²t Voltage drop Pigment
(A²Sec)
DFN-E DFN-E-20 20 3500 100 (Yellow)
DFN-E-30 30 8200 97 (Green)
DFN-E-40 40 14200 93 (Orange)
DFN-E-50 50 22500 90 (red)
DFN-E-60 60 23000 95 (Blue)

Currentcharacteristiccurve

Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard

Performance criteria

Test current item(A) Current Minimum time(s) Maximum time(s)
110% 20A-60A 360000s -
150% 20A-60A - 1800s
200% 20A-60A 2s 60s
350% 20A-60A 0.20s 7s
600% 20A-60A 0.040s 1s

UL Certificate

Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard

Test equipment
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Production equipment
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
Our Certificates
Car Blade Automotive Replacement Fuses 60A Rated Current ISO8820 Standard
