15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
Specifications
Brand Name :
HWTX
Model Number :
TX150*50
Place of Origin :
China
MOQ :
2
Price :
Price Negotiation
Supply Ability :
500pcs/month
Delivery Time :
15days
Packaging Details :
Wooden Case
Screen Size :
15 inches
Resolution :
1024×768
Brightness :
3000 cd/m²
Operating Temperature :
-20°C to +70°C
Module Thickness :
≤12 mm
Backlight Lifespan :
≥50,000 hours
Description
15" 1024×768 High Brightness LCD Module | 3000 nits for Industrial Vision
This 15-inch industrial-grade LCD display module is specifically designed for industrial vision, machine inspection, outdoor terminals, and high-brightness environments. It features an original high-brightness LED backlight solution with a surface brightness of 3,000 nits (cd/m²), ensuring clear and readable images even under direct sunlight or in brightly lit factory environments.
With a resolution of 1024×768 (XGA), the module balances display detail with system compatibility, making it suitable for vision inspection, embedded industrial control equipment, medical imaging terminals, and maritime display systems.
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
Technical Specifications
Screen Size 15 inches (diagonal)
Resolution 1024 × 768 (XGA)
Aspect Ratio 4:3
Brightness 3000 cd/m² (typical)
Backlight Type Industrial-grade LED, high-brightness, long-life, direct-lit backlight
Operating Temperature -20°C to +70°C
Storage Temperature -30°C to +80°C
Interface Types LVDS / VGA / HDMI (customizable)
Surface Treatment Anti-glare / Optical bonding (optional)
Module Thickness ≤12 mm (excluding structural components)
Lifespan ≥50,000 hours (LED backlight)
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
Key Features
  • Ultra-high brightness of 3000 nits - Fully viewable in direct sunlight. Ideal for outdoor smart devices, in-vehicle displays, high-brightness factory environments, and industrial vision applications.
  • 1024×768 XGA resolution - Proven industrial-standard resolution. High compatibility, suitable for various machine vision algorithms and embedded systems.
  • Industrial-Grade Reliability - Wide operating temperature range (-20°C to +70°C). Vibration- and shock-resistant design. Suitable for vision inspection equipment, CNC machine tools, harsh industrial environments.
  • Module Form Factor for Flexible Integration - Pure LCD module, without housing. Supports customer-defined structures, touchscreens, and protective glass. Offers customization options such as optical bonding, anti-reflective coatings.
15 Inch 3000 Nits Industrial LCD Module with 1024×768 Resolution for Machine Vision
Typical Applications
