Specifications
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
bowl
Place of Origin :
Jiangsu, China
Brand Name :
HUADING
warranty :
1 Year
productivity :
/
weight (kg) :
3000 kg
Bowl diameter :
186 - 720 mm
Bowl speed :
2000 - 6000 rpm
Primary motor :
5.5 - 132 Kw
G-forcee :
1600 - 4000 g
Secondary motor :
2.2 - 45 Kw
Material :
EN 1.4462 / 1.4362 / 1.4410 / 1.4501 / AISI 304 / 316 / 316L
Noise :
< 88 dB
After Warranty Service :
Field maintenance and repair service
Local Service Location :
worldwide
Condition :
New
Applicable Industries :
Construction works , Energy & Mining, Food & Beverage Factory, Manufacturing Plant
Showroom Location :
Canada, Germany, South Africa, United States
Marketing Type :
New Product 2020
Warranty of core components :
5 year
MOQ :
1 set
Price :
$18,000 / set
Description
Customized Horizontal Continuous Screw Decanter Centrifuge
Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices
Product Features
The rotating part of these decanter tricanter centrifuges is mounted on a compact, in-line frame with main bearings at both ends. Vibration dampers are placed under the frame. The rotating part is enclosed in a casing with a cover and a bottom section with integrated outlets for both solids and the liquid being removed.
Quality Assurance & Certifications
  • JB/T502-2015 Chinese national standard of decanter centrifuge
  • 2006/42/EC Machinery Directive
  • 2014/35/EU Low voltage Directive
  • 2014/30/EU Electromagnetic compatibility Directive
  • Quality management system of ISO9001-2000
Technical Specifications
Specification Range
Bowl Diameter 186-720mm
Bowl Length 744-3000mm
Bowl Speed 2000-6000rpm
G-Force 1600-4000g
Weight 600-8000kg
Primary Motor 5.5-132kw
Secondary Motor 2.2-45kw
Material AISI 304/316/316L/Duplex Steel
Noise Level <88db
Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices
Drive System Options
Single Motor Drive
This is a very simple design that is cost-effective to purchase and operate. Single motor drives are used when the solids volume is constant, the solids are easy to convey, and requirements regarding the residual water content of the solids are not very stringent. The input shaft of the drive is set in motion by the main motor via a second belt drive, generating differential speed as a function of bowl speed and gear transmission.
Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices
Dual Motor Drive
This system enables cost-effective differential speed regulation under good operating conditions with wide regulating ranges. The secondary motor sets the input shaft of the gear in motion and generates differential speed as a function of bowl speed and gear transmission. Dual motor drives are used when solid volumes fluctuate significantly, when solids are conveyed under difficult conditions, and when stringent requirements apply to residual water content.
Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices
Hydro Drive System
This system operates similarly to the dual motor drive but features a different design. Instead of mechanical gearing, a rotating hydromotor is installed and supplied with hydraulic regulation by a pump unit. Since the differential speed is proportionate to the conveyed quantity of oil, automatic regulation can be provided without any problem.
Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices
Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices Customized Horizontal Continuous Screw Decanter Centrifuge with Factory Prices
Frequently Asked Questions
How can we visit your factory?
International visitors arriving at Shanghai Airport or domestic visitors arriving at Yixing Station will be provided with transportation to our facility.
How do you guarantee the quality of your products?
With over 60 years of experience, we implement strict quality policies using advanced processing machines, certified operators, and internationally renowned components. Comprehensive testing and inspection occurs throughout production.
What payment methods does your company accept?
We accept most payment methods, primarily T/T (Telegraphic Transfer).
How long is the warranty period of your products?
12 months warranty coverage.
How can I trust your company as a new customer?
We have been established on for 14 years and provide all necessary certifications and documentation.
What are your shipping terms and delivery time?
Each unit is customized with delivery times of 60-90 days.
Do you offer discounts?
We strive to provide the best possible pricing for all our customers.
