Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
Specifications
Brand Name :
HUADING
Certification :
CE ISO
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
$24,000-25,000 / set
Payment Terms :
T/T,Western Union
Supply Ability :
40 set / months
Delivery Time :
60 working days
Packaging Details :
Standard seaworthy package
core components :
Motor, Bearing, PLC
Application :
Food chemicals, Fruit and vegetable beverages
Material :
Stainless Steel
Bowl weight :
50-15000 Kg
Solids holding space :
2 - 50 L
Inlet pressure :
0-0.1 Mpa
Liquid outlet pressure :
0.2-0.6 Mpa
Structure :
vertic disc type
Description
Company Advantages
60+Years Experience
40000+Installations
100+Centrifuge Models
Huading Separator is one of the market leaders in centrifugal separating technology, with over 60 years of experience developing and manufacturing disc stack centrifuges. Our equipment is trusted by well-known manufacturers worldwide in food, pharmaceutical, and industrial applications
Centrifugal Separation Technology
The disc stack separator separates solids and one or two liquid phases from each other in one single continuous process, using extremely high centrifugal forces. When the denser solids are subjected to such forces, they are forced outwards against the rotating bowl wall, while the less dense liquid phases form concentric inner layers.
Technical Specifications
Dimensions 2000 × 1200 × 1800mm
Drive gear / belt
Bowl speed 4000 - 10000 rpm
Centrifugal force > 10,000 g
Bowl volume 8 - 300 L
Bowl weight 50-15000 Kg
Solids holding space 2 - 50 L
Inlet pressure 0-0.1 Mpa
Liquid outlet pressure 0.2-0.6 Mpa
Starting time 5 - 30 mins
Stopping time (no brakes) > 40 mins
Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
Process Components

1 Inlet tube

2 Central bore

3 Distributor

4 Distributor bore

5 Rising channels

6 Light phase centripetal pump

7 Heavy phase centripetal pump

Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
2-Phase Separation Process
Separation takes place inside a rotating bowl. The feed is introduced to the rotating centrifuge bowl from the top via a stationary inlet pipe, and is accelerated in the distributor before entering the disc stack. The separation of liquid-solids takes place between the discs, with the liquid phase moving through the disc stack to the centre and pumped out via built-in paring disc.
Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
3-Phase Separation Process
The suspension to be separated is fed into the separator bowl from the top through a feeding pipe and enters the disc stack. The heavy phase and heavy sludge are forced towards the periphery of the bowl, while the light phase flows towards the centre. Solids collects in the sludge space and is discharged intermittently and automatically.
Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
Manufacturing Excellence
Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification Industrial Disc Oil Separator Providing Effective Oil Separation Solutions for Compressed Air Systems and Process Air Purification
Packaging & Shipping
Package: Standard export carton packing
Delivery Time: 30-90 days after confirming order (varies by production season and order quantity)
