Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Juneng
Certification :
CE / ISO
MOQ :
1 set
Price :
$30,000-40,000 / set
Voltage :
220V / 380V / 460V
Power :
15000W
Dimensions :
1800*1200*2030 mm
Weight :
2000 KG
Capacity :
3000-7000 l/h
Rotation speed :
6600 rpm
Material :
SUS304/SUS316
Inlet pressure :
0.05 Mpa
Outlet pressure :
0.1-0.4 Mpa
Motor power :
15 Kw
Core components :
PLC, Bearing, Motor
Treatment capacity :
3000-7000 L/H
Noise level :
Lower
Drum material :
SUS304/SUS316
Base material :
Steel with damping rubber
Description
Disc Bowl Milk Cream 3 Phase Separator Machine
Product Application
Juneng dairy separator features large capacity, excellent deoiling performance, high efficiency, and lower energy consumption. The advanced inlet and outlet design ensures gentle treatment throughout the separation process, preventing destructive air from entering and maintaining product quality.
Milk products vary widely in composition, from simple milk with different fat contents to diverse dairy products including butter, cheese, quark, and yogurt.
Main Features
  • High rotating speed
  • Operating stability
  • Completely sealed inlet and outlet system
  • Lower noise operation
  • Perfect separation efficiency
Technical Specifications
Model Treatment capacity (L/H) Inlet Pressure (Mpa) Outlet pressure (Mpa) Motor power (Kw) Weight (Kg) Outline dimension (mm)
DHNZ204 1000-1500 0.05 0.1-0.2 4 520 810*850*1350
DHNZ360 1000-3000 0.05 0.1-0.3 7.5 1200 1530*1150*1500
DHNZ470 3000-7000 0.05 0.1-0.4 15 1600 1800*1200*2030
DHNZ550 5000-10000 0.05 0.1-0.4 22 2300 1950*1550*1960
Detailed Components
Disc
Brand: Juneng | Origin: China
Shaft
Brand: Juneng | Origin: China
The vertical shaft transmits power and is equipped with speed step-up gear (small spiral gear) and high-speed rotating parts. The cross shaft transmits motor power to the vertical shaft and main drum components.
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Drum
Brand: Juneng | Origin: China
The drum is the high-speed rotating component that performs material separation, serving as the heart of the separator.
Equipment Base
Brand: Juneng | Origin: China
The underframe supports the entire separator and connects to the base. All four supporting feet feature damping rubber pads that effectively isolate vibration between the separator and building.
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Quality Testing & Inspection
  • Material Test Report
  • Magnetic Particle Examination
  • Nondestructive Examination
  • Liquid Penetrant Examination
  • Dynamic Balancing Test
  • Radiographic Examination
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Our Services
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Pre-Sales Service
  • Inquiry and consulting support
  • Sample testing support
  • Factory viewing opportunities
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
After-Sales Service
  • Machine installation training
  • Operation training
  • Overseas engineer support
We maintain a dedicated division to support on-site services domestically and internationally. Upon order, our technical engineers will assist with equipment installation to ensure smooth operation and provide operator training.
Certifications
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Exhibitions
We have participated in numerous international exhibitions including ACHEMA, AchemAsia 2019, ProFood Tech, 21st Interphex Week Japan, and both Spring and Autumn Canton Fairs.
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Packing & Delivery
Industrial Milk Cream Separator with SUS304/SUS316 Material 3000-7000 L/H Capacity and 6600 RPM Setting Speed
Packaging Size 123 (L) * 456 (W) * 789 (D)
Weight 1.2 T
Standard packaging uses wooden boxes (Size: L*W*H). For European exports, wooden boxes are fumigated. For tight containers, we use PE film or accommodate special customer packaging requests.
