Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Specifications
Brand Name :
Juneng
Place of Origin :
Jiangsu, China
Certification :
CE ISO
MOQ :
1
Price :
CN¥219,951-271,490.53
Flow rate :
1500-3500 L/h
Power :
4-6 kW
Voltage :
Customer's Requirement
Material :
Stainless Steel 304
Capacity :
1500-3500 L/h
Motor Power :
4 Kw
Outline Dimension :
918*545*940 mm
Rated Treatment Capacity :
1500 Liter/Hour
Core Components :
Motor
Weight :
determined by model
Dimension :
determined by model
Applicable Industries :
marine diesel oil
Heavy Phase Output :
Centripetal pump
Light Phase Output :
Centripetal pump
Backpressure Regulating :
Yes
Description
Product Description

Product Application

The heavy diesel oil is separated by separator can replace the light diesel oil for using so that reduce the cost of production greatly.

The marine separator is mainly used for cleaning up the moisture and mechanical impurity in the fuel ( Light diesel oil, heavy diesel oil, fuel oil) and lubricating oil of ships and diesel engine, which is good to reduce the abrasion and prolong its service-life.

The design, manufacture and inspect are accord with GB/T5745-2002 << Marine Disk Separator>>. Stable operation, the vibration is much lower than the national standard value. All materials are made of stainless steel, so effectively reduce the corrosion of separation materials.

.

SPECIFICATIONS FOR MARINE SEPARATOR

KYDR204DD-23
Rated Treatment Capacity
Liter / Hour
1500
Motor Power
Kw
4
Outline Dimension
mm
918*545*940
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support

Main Features

1) There are stationary centripetal pumps for heavy phase and light phase output. Separated heavy phase and light phase are outputted respectively by the large and small centripetal pumps which on the top of the drum.

2) This series of separator outfits various specific gravity rings with different diameter, which can be selected and used according to the density and volume of the materials.

3) It has backpressure regulating valve. Separating effect can be regulated by regulating backpressure.

Certifications
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Company Profile
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support

Jiangsu Juneng Machinery Co., Ltd in Yixing

We are professional in manufacturing disc separators and liquid pumps.If you would have any plan on these items,please feel free to contact us. We are happy to recommend the most suitable model for you.

Packing & Delivery
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Packaging
Transport
Ocean shipping sea transportation transport by sea
Container
20'GP, 40'HC or Shipping LCL



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Our Service
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support
Stainless Steel 304 Marine Diesel Oil Separator with 1500-3500 L/h Capacity and Overseas Service Support

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
