CONDOR FIX THERM INLINE EX THERMOSTAT IL-*/* EXPLOSION PROOF THERMOSTAT

Specifications

Ambient Temperature Range :

-55 °C … + 65 °C

Voltage :

6A / 240 VAC

Mounting bracket :

available (B)

Housing Material :

Aluminium covered with heat-shrink tube

Set-point tolerance :

+/- 3°C

Hysteresis :

ca. 2°C

Overall dimensions :

o.d. ca. 25 mm x 44 mm length

Payment Terms :

T/T

Material cable :

silicone cable, outer diam. ca. 7.4 mm

weight :

ca. 30 g.

MOQ :

1pcs

Certifications :

DEKRA 13ATEX0176 and IECEx DEK 13.0062

Place of Origin :

Mauritius/Netherlands/Spain

Price :

EURO/USD/HKD

Delivery Time :

2-4 weeks

Packaging Details :

carton

cable :

3x 1 sqmm

Power Source :

Electric

Standard length :

ca. 1 mtr

Certification :

ATEX,EU,Cu-Tr,Iecex,Ktl

Model Number :

Ex THERMOSTAT IL-*/*

Switch :

SPST

Brand Name :

condor

Features :

Setpoints up to 135°C

Other lengths :

on request

EX protection class :

ATEX 2 II G Ex mb IIC T6 Gb, 2 II D Ex mb IIIC T85°C Db;

color :

black

Description

1 Application

The FixTherm Inline Thermostats are often used as maximum thermostat in instrumentation cabinets with space-heating, to protect the equipment from overheating.Prevention of overheating Temperature protection

2 Features and Advantages

Setpoints up to 60°C
Accurate set-point (± 3°C)
Small hysteresis
Suitable for T6 classification
Can be used for 6A / 240 VAC/DC

3 Remarks

The housing is made from covered aluminium.
When required in applications it is normal practice to use our Space-heaters and Direct-heaters in combination with this FixTherm Inline Thermostat(range from 10°C up to 60°C).

4 Range

IL-10/5 – going up with 5°C setpoints e.g. 10/5 – 15/10 – 20/15 etc. up to 60°C maximum.

5 Technical data

Housing Aluminium covered with heat-shrink tube
Current / voltage 6A / 240 VAC
Cable 3x 1 sqmm
Material cable silicone cable, outer diam. ca. 7.4 mm
Standard length ca. 1 mtr
Other lengths on request
Overall dimensions o.d. ca. 25 mm x 44 mm length
Weight ca. 30 g.
Switch SPST
Set-point tolerance +/- 3°C
Hysteresis ca. 2°C
Ambient temp. range -55 °C … + 65 °C
EX protection class ATEX 2 II G Ex mb IIC T6 Gb, 2 II D Ex mb IIIC T85°C Db;
IECEx Ex mb IIC T6 Gb, Ex mb IIIC T85°C Db
Certification DEKRA 13ATEX0176 and IECEx DEK 13.0062
