Specifications
Warranty :
2 yrs
Type :
signal generator
Customized support :
OEM, ODM
Place of Origin :
Anhui, China
Brand Name :
ZHICE-ELEC
Model Number :
603H
Product name :
multifunction loop calibrator
Application :
Measure, Simulate, Output process signal
Function :
voltage & mA
Feature :
provide 24V loop power
Communication :
HART, 232 and Bluetooth
Power Supply :
Battery
Working temperature :
-10~55℃
Size :
170*75*45mm
WEIGHT :
510g
MOQ :
1pc
Packaging Details :
Provide soft bag & standard carton
Supply Ability :
10 Set/Sets per Month
MOQ :
1 piece
Price :
$460.00/units 5-19 units
Description
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
603H loop calibrator is a time-saving solution and generate high-quality results.
603H comes with HART communication function and supports one selected group of HART general instructions and general application instructions.
603H is a cost effective and compact loop calibrator; and a powerful HART communication tool.
603H has a built-in universal HART modem to execute the following commands:
read information; read tags, descriptors and calibration date; read sensor PV information; read PV output information;
read long tags; write PV range (upper and lower limit); write the main variable unit, short address and short label; enter/exit
the fixed current mode; adjust the zero point offset; fine-tune the DAC zero point (mA output: 4mA); fine-tune the DAC gain (mA output: 20mA)
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Measure
Range
Measuring
Range
Resolution
Accuracy
Current measurement with mA clamp
20.99mA
0-20.99mA
0.01mA
0.2% + 5LSD
100mA
21-100mA
0.1mA
1% + 5LSD
Current measurement
24mA
0-24mA
0.001mA
0.01% + 2LSD (23℃ +5℃ full range)
Current measurement
with 24V voltage
24mA
0-24mA
0.001mA
0.01% + 2LSD
(23°C+5°c full range)
Voltage measurement
30V
0-30V
0.001V
0.01% + 2LSD
(23°C+5°C full range)
Source
Range
Measuring
Resolution
Accuracy
Current sourcing
24mA
0-24mA
0.001mA
0.01% + 2LSD
(23°C+5°C full range)
Current simulating
24mA
0-24mA
0.001mA
0.01% + 2LSD
(23°C+5°C full range)
Voltage sourcing
10V
0-10V
0.001V
HART communication
603H comes with HART communication function
HART resistor
250Ω
Loop power voltage
24C DC@20mA
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator
Multifunction Handheld Loop Calibrator Current Voltage 4-20mA HART Signal Generator

Q: Are you a trading company or manufacture? A: We are a professional manufacture specialized in temperature humidity instrument and environment monitor system for 20 years.
Q: Who are we? A: We have a complete product line of precision temperature measurement and control such as temperature sensors, transmitters, temperature detection instruments and temperature calibration equipment.
Q: Is there any stock? A: Yes,we have materials in stock to help you to get the samples as soon as we can.

Q:Why to choose Hefei Zhice-elec products ? 1.Instruments has been exported to over 50 countries. 2.100% QC inspection Before Shipment. 3.ISO,CE,SGS standard and factory price. 4.Our instruments has been 100% recognized by Bureau of National Metrology. 5.Excellent product quality and strong technical support capability.
