Specifications
Brand Name :
Sinowon
Model Number :
DigiRock-HR1
Certification :
CE
Place of Origin :
Dongguan China
MOQ :
1 Set
Payment Terms :
T/T, L/C
Packaging Details :
Plywood Box
Rockwell Scales :
HRA, HRB, HRC
Preliminary Force :
10Kgf
Resolution :
0.5HR
Hardness Indication :
Dial Gauge
Vertical Space :
175mm
Horizontal Space :
165mm
Description

Manual Loading Dial Gauge Rockwell Hardness Tester with vertical space 175mm

Features:


● DigiRock HR1 analogue gauge resolution is 0.5HR, it is useful to improve the reading accuracy than traditional 1HR resolution;


● DigiRock HR1 force knob adopts the metal material to replace the plastic, it largely improves the instrument using-life;


● DigiRock HR1 loading, dwell and unloading is buffering by oil pump,it eliminates the operator' s tiredness;


● DigiRock HR1 intenter protector is available to improve the using lifetime of indenter.

Manual Loading Dial Gauge Rockwell Hardness Testing Equipment With Vertical Space 175mm

Specifications:

Product Name Electronic Superficial Rockwell Hardness Tester
Model DigiRock HR1
Code# 811-110
Rockwell Scales HRC ,HRB, HRA
Preliminary Test Force 10Kgf(98.07N)
Test Force 60Kgf(558.4N),100Kgf(980.7N),150Kgf(1471N)
Dwell Time Adjustable 1-60s
Hardness Indication Analogue Display
Resolution 0.5HR
Loading Control Manual

Max. Height

Of Specimen

 175mm
Instrument Throat 165mm
Dimension(LxWxH) 520 x215 x700mm
Packing Dimension 630 x440 x960mm
Gross/Net Weight 120Kg/90Kg
Execution Standard ISO 6508,ASTM E18,JIS Z2245,GB/T230

Manual Loading Dial Gauge Rockwell Hardness Testing Equipment With Vertical Space 175mm

Standard Delivery:

Product Name Code# Product Name Code#
Instrument Main Body 811-110 Ø1.588mm Steel Ball 811-421
Hardness Block (57-70) HRC 811-641C

Cone Diamond Indenter

 811-401
Hardness Block (20-33) HRC

811-611C

 Ø 150mm Flat anvil 811-541
Hardness Block (85-100) HRB

811-641B

 Ø 40mm V-shape Anvil 811-511
Ø1.588mm Ball Indenter 811-411 Weight A 811-711
Accessories Box 811-901 Weight B 811-721
Anti-dust Cover 811-911 Weight C 811-731
Qualified Certificate DigiRock HR1

Instrument Manual

 DigiRock HR1

Manual Loading Dial Gauge Rockwell Hardness Testing Equipment With Vertical Space 175mm

Optional Accessories:

Optional Accessories Code# Optional Accessories Code#
1/8" Steel Ball Indenter 811-431 1/8" Steel Ball 811-441
1/4" Steel Ball Indenter 811-451 1/4" Steel Ball 811-461
1/ 2" Steel Ball Indenter 811-471 1/2" Steel Ball 811-481
100mm Flat Anvil 811-531 Small Flat Anvil 811-501

Manual Loading Dial Gauge Rockwell Hardness Testing Equipment With Vertical Space 175mm
