Plc Power Supply Isolated DC/DC Converters DIN Rail Mount 20A Redundancy Unit Switching Power Supply S8VK-R10 S8VK-R10

Contribute to build high reliable systemsCompact and Cost-effective solutionfor Back-up applicationsEasy setup for system reliabilityrequirement• Redundancy operating LED for the status confirmation• A signal output for failure detection of power supplies• Wide range inputDC5-30V (S8VK-R10), DC10-60V (S8VK-R20)• Wide operation temperature range: -40 to 70 °C• Safety standards:UL 508, CSA C22.2 No. 107EN 62477-1• EMS: EN61000-6-2EMI: EN61000-6-3Lloyd's standards• Three years warranty ** Refer to Period and Terms of Warranty on page 11.

Power Boost FunctionThis function is possible when used in combination with S8VK-G (AllModels).Power Boost is a function that can output the temporary repeatedboost current larger than the rated current.However, it should meet the following four Boost current conditions.1. Time that the boost current flows: t12. The maximum value of the boost current: lp3. The average output current: lave4. The time ratio of the boost current flow: Duty

• Do not allow the boost current to continue for more than 10seconds.Also, do not let the duty cycle exceed the boost current conditions.These conditions may damage the Power supply.• Ensure that the average current of one cycle of the boost currentdoes not exceed the rated output current.This may damage the Power Supply.• Lessen the load of the boost load current by adjusting the ambienttemperature and the mounting direction.

Wiring1. Minor fire may possibly occur. Ensure that input and outputterminals are wired correctly.2. Increases in the temperature of internal parts resulting fromheating of wiring materials may result in deterioration or damageto parts. Use wiring materials suitable to the current being used.The following wiring materials and strip length are recommendedto prevent heating and possible fires in wiring materials.Input side: Use the following recommended wire type or therecommended wire type of the connected powersupply.Output side: Use the following recommended wire type or a wiretype that has sufficient capacity for the current of thetwo connected power supplies.

Packaging and transportation instructions

- According to the standard export packaging.

Customers can choose from cartons, wooden cases and wooden pallets according to their own requirements.
