This 55-inch floor standing digital signage features a commercial-grade LCD panel with Full HD resolution of 1920 × 1080, delivering sharp and vivid visuals for close-range interactive viewing. The zero-bonding assembly process ensures a clear, natural image with excellent light transmission, while wide 178° viewing angles maintain consistent image quality from all directions.

Brightness can be adjusted between 260 and 450 cd/m² to suit different indoor lighting conditions, making it ideal for shopping malls, office lobbies, banks, and exhibition spaces. The display operates at a 60Hz refresh rate with an 8ms response time for smooth visual performance.

1. Input Voltage: AC 110–240V, 50/60Hz
2. Typical Power Consumption: 90W
3. Standby Power: ≤ 0.5W
4. Panel Lifespan: ≥ 50,000 hours

1. Operating Temperature: -10°C to 55°C
2. Storage Temperature: -20°C to 60°C
3. Operating Humidity: 10%–90% RH (non-condensing)

The display is equipped with a high-precision capacitive touch screen supporting up to 10-point multi-touch interaction under PC systems. Touch input is fast, accurate, and highly responsive, enabling smooth gestures such as tapping, swiping, zooming, and handwriting.

A 3mm tempered safety glass surface enhances durability and protects the screen from impact while maintaining excellent touch sensitivity. The HID driver-free design allows plug-and-play operation via USB connection, with no additional drivers required.

Designed primarily for vertical (portrait) installation, this floor standing unit can also support landscape orientation if required. The ultra-narrow bezel design maximizes visible screen area and gives the kiosk a clean, modern appearance suitable for premium commercial environments.

The enclosure features an anodized aluminum alloy frame with a reinforced steel rear housing and active heat dissipation for long-term stable operation.

The unit is supplied with Android 11.0 as standard, powered by an RK3566 quad-core Cortex-A55 processor with a maximum frequency of 1.8GHz. It includes 2GB DDR4 RAM and 16GB internal storage, supporting smooth multimedia playback and interactive applications.

Windows and Linux system solutions are also available as optional configurations to support customized software platforms.

Built-in Wi-Fi (2.4GHz) enables easy network connectivity. Standard interfaces include USB ports, RJ45 LAN, HDMI output, headphone jack, and TF card slot, allowing flexible integration with external devices and content sources.

The digital signage includes dual built-in 5W speakers, suitable for indoor advertising and interactive content. It supports a wide range of multimedia formats, including H.265, H.264, and VP9 video decoding (up to 4K @ 60fps), as well as common audio formats such as MP3, AAC, FLAC, and OGG.

This model supports floor standing installation and VESA mounting (400 × 300 mm). Rear or side access design allows convenient maintenance and quick servicing without dismantling the entire unit.
