New original Sick inductive Proximity Sensor IMB12-04BNSVW5S With Best Price

Specifications

Brand Name :

Sick

Model Number :

IMB12-04BNSVW5S

Certification :

Place of Origin :

Germany

MOQ :

Price :

USD20/PC

Payment Terms :

L/C, D/A, D/P, T/T, Western Union

Supply Ability :

1000

Delivery Time :

2weeks

Packaging Details :

Original

warrany :

1 year

enclosure protection class :

IP68

Residual ripple :

≤ 10 %

electromagnetic compatibility :

According to EN 60947-5-2

Description

Mechanical/Electronic Parameters

Power supply voltage: 10 V DC ... 30 V DC

Residual ripple ≤ 10%

Voltage drop ≤ 2 V 1)

Hysteresis 3 % ... 20%

Reproducibility

≤ 2 % 2)

Temperature drift (Sr) ± 10 %

Electromagnetic compatibility Compliant with EN 60947-5-2

Continuous current Ia ≤ 200 mA

No-load current ≤ 10 mA

Conductor material PVC

Conductor cross-sectional area 0.25 mm²

Conductor diameter Ø 3.9 mm

Short-circuit protection ✔

Power-on pulse protection ✔

Impact and vibration resistance 100 g / 2 ms / 500 cycles; 150 g / 1 million cycles; 10 Hz ... 55 Hz / 1 mm; 55 Hz ... 500 Hz / 60 g

Operating environment temperature: -25 ℃ ... +75 ℃

Shell material: Stainless steel V2A, DIN 1.4305 / AISI 303

Material for the sensing surface: Plastic, LCP

Shell length: 50 mm

Available screw thread length: 46 mm

Maximum tightening torque: Typ. 20 Nm 4)

Typ. 32 Nm 5)

Protection level: III

UL document number: E181493

1) At Ia max.

2) The working voltage UB and the ambient temperature Ta remain constant.

3) From Sr.

4) Use on the non-threaded surface of the nut.

5) Use on the threaded surface of the nut.

Reduction factor

Note: These data are for reference only and may have some deviations.

Steel St37 (Fe) 1

Stainless Steel (V2A) Approximately 0.65

Aluminum (Al) Approximately 0.35

Copper (Cu) Approximately 0.24

Brass (Ms) Approximately 0.38 Installation Guide

Note: For related diagrams, please refer to "Installation Instructions". B 12 mm

C 12 mm

D 12 mm

F 32 mm

Certificate

EU declaration of conformity ✔

UK declaration of conformity ✔

ACMA declaration of conformity ✔

Moroccan declaration of conformity ✔

China-RoHS ✔

cULus Certification ✔ New original Sick inductive Proximity Sensor IMB12-04BNSVW5S With Best Price
