Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
Specifications
Brand Name :
battery powered flat car
Model Number :
battery powered flat car
Certification :
CE ISO SGS
Place of Origin :
China(mainland)
MOQ :
1 set
Price :
USD 2000~7200 set
Supply Ability :
100 sets month
Delivery Time :
20 work days after received balance payment
Packaging Details :
trap and wooden case
Product Name :
battery powered flat car for industrial handling cart quad steel cart
Material :
Q235
Capacity :
1-300T
Color :
Customized
Application :
Industrial Filed
Warranty :
12 Months
after-sales Service Provided :
Engineers available to service machinery
Description

Battery Power Flat Quad Heavy Load Electric Ferry Transfer Cart for Factories

Introductions

The Crossing Rails Ferry Transport Cart is made up of two parts. The upper car is used for transporting cargo. The upper can can be equipped with V shape support, lifting platform. The down car is usually designed to run underground. The rail is mounted underneath the car and used for connecting with other rails in workshops which makes the upper car be able to run on parallel rails. The Crossing Rails Ferry Transport Cart can realize cargo transfer among crossing rails. It's more convenient and could be used separately compared with rotating platform.

Technical Parameter
Model BXC-5t BXC-20t BXC-30t BXC-40t BXC-50t
Rated Load(t) 5 20 30 40 50
Max. Wheel Load (t) 2.8 5.6 7.7 10 12
Ground Requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table Size (mm) 3000 X 2000 4500 X 2200 5000 X 2200 5500 X 2300 6000 X 2300
Height (mm) 450 600 650 700 700
Wheel Base (mm) 1500 1700 1700 1800 1800
Axles Distance (mm) 2500 3900 4300 4800 5200
Turning Radius (mm) 2501 3901 4301 4801 5201
Turning Structure Mechanical
Motor Power (KW) 3.5 7 10 12 15
Wheel Diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel Material ZG55+hydropurture
Running Speed (m/min) 0-15 0-12
Brake Principle Electric magnetic brake
Operation Method Raido Remote Control
Battery Maintainance Free of maintainance
Charger's Installation Installed on cart Split-type
Cart Color Customized
Charger's Function Automatically cut off the power when the battery is fully charged
Radar Control 3-0.3 m, Automatic stop for obstacles
Warning Equipment Horn and Flash Light
Other Functions Turning light, night light and power display

Feature of cart

---- Low noise It causes low noise level.
---- Maximum safety Offers guarantee of maximum safety for operators and for the material handled. We really care about the safety of everyone involved in the job.
---- Easy for operation These transfer carts are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best out of your heavy load transporter.
---- Easy to implement into manufacturing process Operates on standard floors; Do not require complex or permanent installation
---- Suitable for All Kinds of Weight The battery powered trolley is superb for handling both small and extremely huge loads for its modular fabrication and its high payloads: up to 300 ton for each trolley.

Flat Quad Electric Ferry Transfer Cart Battery Power Heavy Load For Factories
