WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines
Specifications
Brand Name :
WESPC
Model Number :
1827121C2
Certification :
ISO9001
Place of Origin :
China
MOQ :
10
Price :
$3-$6(1 Piece)
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
In stock
Delivery Time :
5-10 work days
Packaging Details :
carton
Product Name :
Valve Seat Inlet 1827121C2
Condition :
100%new
Quality Class :
High-Quality
Stock :
Yes
Warranty :
1year
Packaging :
Carton
Description

WESPC Valve Seat Inlet 1827121C2 For Navistar Perkins DT466E DT530E HEUI Engines

Brand Name WESPC
Place of Origin China

Part Number

 1827121C2
After-sales Service Provided Video Technical Support, Online Support
Marketing Type Ordinary Product
Certificate ISO9001
Warranty 1 Year
Stock Yes

Application:

The inlet seat 1827121C2 is specified for Navistar DT466E & DT530E HEUI engines (7.6 L & 8.7 L) and is also catalogued for Perkins 1306C-E87TAG and 1506A-E88TAG series. It is therefore found in Class-6/7 haulers, school buses, 150-300 kVA generator sets, wheel loaders, motor graders and farm tractors that use the same cylinder-head machining.

Technical specifications:

OD 2.0010 in (50.83 mm), depth 0.3560 in (9.04 mm), 30° seat angle, 1.712 in throat ID; interference fit 0.002-0.004 in for cast-iron heads. The 1.870 in top taper blends into the throat to give a 1.8 mm seating width that resists recession under 2.2 bar boost and 750 °C inlet temperature while maintaining airflow for EGR-equipped builds.

Material & performance features:

Vacuum-sintered Co-Cr-Mo steel (≥50 HRC) with 30 % Cr, 1.2 % Mo, 0.8 % V; plasma-nitrided to 0.05 mm depth for 950 HV surface hardness while the core remains tough enough to absorb valve impact. A 0.4 µm Ra finish beds in within 15 min, and the alloy resists low-sulphur diesel, biodiesel and 20 % HVO, giving >12 000 h service before re-cut.

Interchange part numbers:

Navistar 1827121, 1827121C1, Mack 4333-1827121C2, Interstate-McBee M-1827121C2, PAI 491916, SB2001E-2 and 30-2001E-2.
