Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor
Specifications
Brand Name :
SUNRISE
Certification :
CE
Place of Origin :
Zhejiang, China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
30 Set/Sets per Month
Delivery Time :
15 work days
Packaging Details :
exported wooden case
Label width :
10-310mm
Media width :
100-330mm
Cut precision :
0.1mm
Max. roll diameter :
450mm
Media thickness :
60-400um
Machine weight :
Approx. 560kgs
Power supply :
220-240V 1100W
Cut speed :
6m per minute (10*10cm)
Description

High Cutting Precision With Servo Motor For X Y Digital Label Die Cutter

Hightlights

  • Tungsten steel rotary baldes technology
  • High cutting precision with servo motor for X Y
  • Fully automatic tension and feeding control
  • Roll to roll or roll to cut die cutting
  • The slitting speed up to 60m per minute
  • Two rewinders are standard
  • Cutting speed is up to 6m/m

​Key specifications

Technology Tungsten stell rotary blade Cut speed 6m per minute (10*10cm)

Label width 10-310mm

Media width 100-330mm

Cut precision 0.1mm (duplicate) Media thickness 60-400um

Max. roll diameter 450mm

Machine dimension 1600*1000*1360mm

Machine weight Approx. 560kgs

Power supply 220-240V 1100W

Machine features

2 cutting head Standard (Max. 4 cutting head)

4 slitter unit Standard (Max. 15 slitter) Inline web guide Standard

lamination Standard film liner removal option

waste removal Standard

up rewinder Standard down rewinder Standard

sheet cutter option

Machine

Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo MotorDigital Die Cutting Machine 330mm Width 0.1mm Precision Servo MotorDigital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor

company profile

Digital Die Cutting Machine 330mm Width 0.1mm Precision Servo MotorDigital Die Cutting Machine 330mm Width 0.1mm Precision Servo Motor

Wenzhou Sunrise Macinery Co.,Ltd professionally research and manufacture label die cutting machine, label slitting machine and some related series products, we pay attention to talents and the technical innovation, insist on "technical innovationnational brand' as development strategy, to make company as the leader in after printing machinery line. Sincerity, quality,service is our operation principle, to be brave aggressive pragmatic efficient is our company spirit. We research and manufacture various of types of machines, welcome all old and new customers and friends to visit us!
