Specifications
Brand Name :
SUNRISE
Model Number :
SR-350
Certification :
CE
Place of Origin :
Zhejiang, China
MOQ :
1
Price :
5000-6000usd
Payment Terms :
T/T
Supply Ability :
30 Set/Sets per Month
Delivery Time :
15 work days
Packaging Details :
exported wooden case
Description

Label Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter Counting

product introduction

One researched new product, mostly is used for slitting narrow roll material, it is for high level market with full servo driven system, PLC control system, it can meter and number counting, static eliminator, no material no working etc.

Performance and characteristics

  • machine running controlled by PLC system

  • tension controlled by taper tension

  • Use servo motor instead of normal motor,work stable and precise

  • With meter and quantity counter, quantity counter use Germany sick brand

  • Use EPC web guide

Label Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter CountingLabel Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter CountingLabel Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter Counting

Label Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter Counting

Technical Data

Model SR-350FZ SR-450FZ
Max. Slitting speed 220m/min 220m/min
Max web width 350mm 450mm
Min. Slitting width 15mm 15mm
Cutter installed 8 sets 10 sets
Max. Unwinding Dia 600mm 600mm
Max. Rewinding Dia 600mm 600mm
Air supply 0.8mpa 0.8mpa
weight 800kg 1000kg
Dimension(L*W*H) 1600*1100*1300 1650*1200*1350

Main Parts List:

NO. Parts Name Brand
1 PLC China-tonghang
2 Counting sensor Germany--sick
3 Servo Motor China-tonghang
4 Buttons China-chentai
5 A.C.Contactor French--Schneider
6 Touching-screen China- duocai
7 Epc web guide China
8 Tension controller ZXM-50 Taper tension

Wenzhou Sunrise Macinery Co.,Ltd professionally research and manufacture label die cutting machine, label slitting machine and some related series products, we pay attention to talents and the technical innovation, insist on "technical innovationnational brand' as development strategy, to make company as the leader in after printing machinery line. Sincerity, quality,service is our operation principle, to be brave aggressive pragmatic efficient is our company spirit. We research and manufacture various of types of machines, welcome all old and new customers and friends to visit us!Label Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter CountingLabel Slitting Machine Featuring Servo Motor and PLC Control System for Precise Tension Control and Accurate Meter Counting
