Specifications
Brand Name :
SUNRISE
Model Number :
350YB
Certification :
CE
Place of Origin :
ZHEJIANG CHINA
MOQ :
1 set
Payment Terms :
T/T
Delivery Time :
15 work days
Packaging Details :
exported wooden case
Slitting speed :
120m/min
Max. Roll Width :
350mm
Max. Unwinding diameter :
700mm
Accuracy rate :
±0.10mm
weight :
600kg
Dimension :
1700*1000*1600mm
Magnetic size :
60T-150T
Description

SR-350YB Rotary Blank Label Die Cuting Machine With Slitter

Functional characteristics:

SR-350YB model die cutting and slitting machine is with rotary die cutting function is a new design, it equipped with high accurate rotary die cutting system, this machine is suitable for blank adhesive label material. Die cutting, slitting can be completed in one process. It has the function of automatic meter counting, Automatic stop, web guiding by photoelectric etc functions. This machine has the characteristic of compact structure , fast speed , high efficiency ,easy operation ,accurate slitting and stably running and so on features.

Features:

1. Rewinder and unwinder all are with magnetic tension controller

2. Air shaft automatic inflate air

Model SR-350YB SR-450YB
Slitting speed 120m/min 120m/min
Max. Roll Width 350mm 450mm
Max. Unwinding diameter 700mm 700mm
Max. rewinding diameter 600mm 600mm
Accuracy rate ±0.10mm ±0.10mm
weight 600kg 800kg
Dimension 1700*1000*1600mm 1800*1300*1700mm
Magnetic size 60T-150T 60T-150T

Main Parts:

NO. Parts Name Brand
1 Transducer Taiwan shilin
2 Photoelectric eyes Baideli
3 Proximity Switch Germany--Leuze
4 Relay China--Chnt
5 Buttons French--Schneider
6 A.C.Contactor China--Chnt
7 Counter Ruixiang
