13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
Specifications
Warranty :
3 years
Customized support :
OEM, ODM, OBM
Place of Origin :
Jiangxi, China
Brand Name :
LINSING
Model Number :
24*7.6/8.4*15MM
Material :
High grade diamond
Usage :
300mm-3500mm saw blade
Segment height :
13/15/20mm
Steel core :
5.0-7.2mm
Type :
M shape
Technology :
Cold press and hot press sintered
Color :
Black, silver
Segment :
Multi-layer segments
Certificate :
ISO9001
Packing :
Inner Box+Outer Box
Packaging Details :
The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Port :
Shanghai, Shenzhen, Ningbo, Xiamen, etc
Supply Ability :
50000 Piece/Pieces per Day Dia.250-3500 diamond circular saw blade
MOQ :
200 pieces
Price :
$0.53/pieces 200-4999 pieces
Description

Diamond Segment For Multi-Saw Blade

Multi segment is a kind of diamond tool used in Italian multiblade cutting machine, Chinese multiblade bridge saw machine, or chinese single column multiblade cutting machine It is usually used to cut stone blocks, and it has the characteristics of high cutting efficiency and stable cutting

13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM

Product Features:
1. The segment has good sharpness against different stone cutting.
2. Long lifespan with high cost-effective.
3. Strict QC for stable cutting performance.
4. Segment shape is easy for opening.

Product Specification:

Multiblade segment for granite cutting

Diameter(mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Φ1000 (600-2000)

5.0

24x7.0/6.2x15 (13,20)

Φ1200 (530-2800)

5.5

24x7.4/6.6x15 (13,20)

Φ1400 (460-2800)

6.5

24x8.4/7.6x15 (13,20)

Φ1600 (460-3000)

7.2

24x9.2/8.4x15 (13,20)

Other specifications are available upon request.

Multiblade segment for marble cutting

Diameter(mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Φ1200

4.5

24x5.5x8 (10)

Φ1200

5.0

24x6.0x8 (10)

Φ1200

6.5

24x7.5x8 (10)

Φ1200

7.0

24x8.0x8 (10)

Other specifications are available upon request.

13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM

Contact Us:
Caitlin Mi
Sales representative
WhatsApp/Wechat: 0086-18270195708
JiangXi LINSING Diamond Tools Co.,Ltd
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us.
We are looking forward to forming successful business relationships with new clients from around the world in the near future.

Your special requirements are highly valued.
Please contact us for more details.
