64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw
64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw
64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw
64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw
64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw
64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw
Specifications
Brand Name :
Johnson Tools
Model Number :
1.1.1.9
Certification :
SGS, GB
Place of Origin :
China
MOQ :
5pcs
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union , PayPal
Supply Ability :
100000pcs per year
Delivery Time :
Around 30-35days
Packaging Details :
Plywood or carton
Type :
Diamond Wall Saw Blades
Welding :
Laser Welding
Thickness :
4.5mm or 4.8mm or 5mm
OEM :
Accept
Steel core :
Tensioned core 3.5mm
Package :
Plywood 171x171x17cm
Shipping method :
Suggest by sea
Net weight :
57kg
Description

64inch 1600mm Wall Saws Big Diamond Saw Blades Reinforced Concrete

1. Description of 64inch 1600mm Wall Saws Big Diamond Saw Blades Reinforced Concrete
1600mm wall saw blade is exported more for demolition reinforced concrete construction, including the partial modification and buildings and walls delimotion, opening window holes, doorways, demolition of reinforced concrerte bridges etc. High quality steel core and diamond segments ensure the smooth cutting during the whole using.
As a direct factory, any size could be customized and designed as your request. Floor saw blade is available too.

64 Inch 1600mm Wall Saw Blades Big Diamond Reinforced Concrete Wall Cutting Saw


2. Feature of 64inch 1600mm Wall Saws Big Diamond Saw Blades Reinforced Concrete
1) 100% laser welding technology.
2) Dry cutting.
3) "Single U" type segment good for cooling.
4) High speed&fast cutting, smooth and long cutting life.
5) Fit to 3HP-85HP, or do as your request.
6) Installed for any brand wall saw machine.

3. Specification of 64inch 1600mm Wall Saws Big Diamond Saw Blades Reinforced Concrete
Diameter:1600mm
Segment thickness:4.5/4.8/5mm
Segment height:10/12mm
Inner hole:25.4mm, 50mm, 60mm, 80mm or as your request

Inch Diameter
(mm)		 Segment length
(mm)		 Segment thickness
(mm)		 Segment height
(mm)		 Segment number
(nos)
64" 1600 40 4.8/5 10/12 92


Other size we could do as following

Inch Diameter
(mm)		 Segment length
(mm)		 Segment thickness
(mm)		 Segment height
(mm)		 Segment number
(nos)
24" 600 40 4.8/5 10/12 36
28" 700 40 4.8/5 10/12 40
32" 800 40 4.8/5 10/12 46
36" 900 40 4.8/5 10/12 52
40" 1000 40 4.8/5 10/12 58
48" 1200 40 4.8/5 10/12 68
60" 1500 40 4.8/5 10/12 90

For more information about this item blade, pls conact us now!
