Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Precision 5 Axis Bridge Cutting Machine
Specifications
Brand Name :
Xianda Machinery
Model Number :
Create 450/600
Place of Origin :
Jinjiang, Fujian, China
Certification :
API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
MOQ :
1
Price :
To Be Negotiable
Packaging Details :
Plastic Package, Suitable for Sea Transportation
Delivery Time :
1 month
Payment Terms :
L/C， T/T， D/P， Western Union ，Paypal ，Money Gram， Others
Supply Ability :
1000 Sets/Year
Gross Power :
20.5/24kw
Power Supply :
AC380V/50Hz
Cutting Accuracy :
High Precision
Application :
Stone Processing
Cutting Speed :
High Speed
Water Consumption :
3m³/h
Worktable Rotating Angle :
0-90°/0-360°
Main Motor :
15/18.5kw
Description

5 Axis Bridge Cutting Machine With Precision Accuracy And Speed For Cutting And Milling Function

Product Description:

5 Axis Bridge cutting machine adopt 5 Axis linkage CNC System Control, Bus-based absolute value servo (with memory function for power off), high-precision linear guide rail, ball screw transmission, oil-immersed track structure, with multil-function, high precision, strong stabilitly and other advantages. Its processing functions include: arbitrary-shaped lines, fan-shaped plates, wash basin and special-shaped edge profiling, etc. The equipment has multiple processing functions, wide application small space, and simple operation, lt is a great equipment for stone processing.

Applications:

Its processing functions include: arbitrary-shaped lines, fan-shaped plates, wash basin and special-shaped edge profiling, etc. The equipment has multiple processing functions, wide application small space, and simple operation, lt is a great equipment for stone processing.

Support and Services:

  • Installation and training services to ensure proper setup and use of the machine
  • 24/7 technical support to assist with any issues or questions that may arise
  • Regular maintenance and repair services to keep the machine operating at peak performance
  • Upgrades and customization options to meet specific customer needs

Packing and Shipping:

Product Packaging:

The stone slab cutting machine will be securely packaged in a wooden crate to ensure safe transportation. The machine will be wrapped with foam and bubble wrap to prevent any damage during shipping.

Shipping:

Shipping of the stone slab cutting machine will be handled by a reputable freight carrier. The shipping cost will depend on the destination and will be calculated at checkout. Please allow 2-3 business days for processing and handling before the machine is shipped out.

Parameter Unit Create 450 Create 600
Blade diameter range mm 350-450 350-600
Max processing size mm 3200*2000*120 3400*2000*180
Lifting stroke mm 300 500
Worktable size mm 3200*2000 3400*2000
Table tilting degree ° 0-85° 0-85°
Head rotating degree ° 0-360° 0-360°
Head tilting degree ° 0-90° 0-90°
Air speed m/min 15 15
Repeated accuracy of positioning mm 0.1mm/1000 0.1mm/1000
Main motor kw 18.5(permanent magnetic synchronous motor) 22(permanent magnetic synchronous motor)
Gross power kw 26 30
Water consumption m³/h 3 3
Outline dimension mm 5600*3600*3500 5800*3650*3900
Gross weight kg 6000 7500

Precision 5 Axis Bridge Cutting MachinePrecision 5 Axis Bridge Cutting MachinePrecision 5 Axis Bridge Cutting MachinePrecision 5 Axis Bridge Cutting MachinePrecision 5 Axis Bridge Cutting MachinePrecision 5 Axis Bridge Cutting Machine
